- Page 1 PU-1107-KIT Pure Digital v1.3 HDMI over Single CAT6 Extender Set with Repeater Function OPERATION MANUAL...
- Page 2 Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document. Cypress also makes no commitment to update or to keep current the information contained in this document.
-
Page 3: Safety Precautions
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of re, electrical shock and injury to persons. -
Page 4: Table Of Contents
Table of Contents 1. Introd uc tion.................. 1 2. Ap p lic a tions................. 1 3. Pa c ka g e Contents ..............1 4. System Req uirem ents..............1 5. Fea tures..................2 6. Sp ec ific a tions ................3 7. -
Page 5: Introduction
1. Introduction The HDMI 1.3 transmitter and receiver over ONE CAT 6 is a tool for extending your HDMI signal over long distances to a compatible display. Instead of using expensive HDMI cables, your existing CAT 6 cables/sockets can be utilized to perform advanced functions like transferring Deep Color (12 bits/ color) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, with a bandwidth up to 225MHz. -
Page 6: Features
5. Features HDMI 1.3, HDCP 1.1 and DVI1.1 compliant. Supports digital video formats in Deep Color Mode at up to 36 bits (12bits/ color) and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) Digital audio . Uses one CAT-6 cable for data/DDC transmission. -
Page 7: Sp Ec Ific A Tions
6. Specications Frequency Bandwidth 2.25Gbps (single link) Transmitter Input/Output Ports 1 x HDMI Female port/1 x CAT6 Receiver Output/Input Ports 1 x HDMI Female port/1 x CAT6 Power Supply 5V/1A DC (US/EU standards, CE/FCC/UL certied) ESD Protection Human Body Model: 8kV (air-gap discharge) ... -
Page 8: Operation Controls And Functions
7. Operation Controls and Functions 7.1 Front Pa nel CH-1107TX CH-107RX DC 5V DC 5V HDMI INPUT HDMI OUT HDMI INPUT: This slot is where you connect the HDMI or DVI output port of your source equipment such as DVD/Blu Ray players or Set-top- boxes with an HDMI cable or link up with another receiver unit from the same family to extend a signal over long distances. -
Page 9: Rear Panel
7.2 Rea r Pa nel CH-1107TX CH-107RX CAT6 OUT CAT6 IN EDID 10 Bit TV/STD 12 Bit 8 Bit EDID Control Switcher: Switch the EDID between STD and TV. Switch to STD to use the built-in EDID or switch to TV to use the TV’s EDID. The default factory setting is TV, leave as is when the display is working properly. -
Page 10: Connection And Installation
8. Connection and Installation HDMI CAT6 HDMI Cable Cable Cable LCD TV CH-1107TX CH-107RX... -
Page 11: Acronyms
Acronyms Acronym Complete Term CAT6 Category 6 Cable EDID Extended display identication data HDMI High-Denition Multimedia Interface... - Page 12 www.cypeurope.com...
