- Page 1 PU-106 v1.3 HDMI over CAT6 Extender Set with IR Pass-through OPERATION MANUAL PU-106_Manual-EN.indd 1 26/04/2011 12:50:05...
- Page 2 Table of Contents Introduction Features Package Contents Operation Controls and Functions Front Panel Diagram Rear Panel Diagram Connection Diagram Specifications PU-106_Manual-EN.indd 2 26/04/2011 12:50:19...
-
Page 3: Package Contents
All the PUMA, HDMI over CAT5e/6 transmitters and receivers are the perfect solution to extend HDMI signals via CAT cabling up to 40m. The PU-106 also allows you to use your existing Remote Control to control your device with the included IR Receiver &... -
Page 4: Operation Controls And Functions
4. Operation Controls and Functions 4.1 Front Panel POWER 5V POWER 5V HDMI OUTPUT HDMI INPUT Receiver Transmitter 1. HDMI input: Connect the HDMI input port to the HDMI or DVI output of your source equipment such as DVD player or set-top-box. 2. - Page 5 4.2 Rear Panel VIDEO VIDEO CAT6 OUTPUT CAT6 INPUT 1. DDC input/output: Connect the DDC output of 106TX to the DDC input of the receiver unit using CAT-6 cable. 2. Video input/output: Connect the video output to the video input of the receiver unit using CAT-6 cable.
-
Page 6: Connection Diagram
5. Connection Diagram 6. Specifications Transmitter: 1x HDMI female port, 1x IR jack, Input Port Receiver: 2 x CAT5e/6, 1 x IR Jack Transmitter: 2 x CAT5e/6, 1 x IR Jack Output Port Receiver: 1x HDMI female port, 1x IR jack 2 x 5V/2.6A DC (US/EU standards, CE/FCC/UL Power Supply certified) - Page 7 Notes: PU-106_Manual-EN.indd 5 26/04/2011 12:50:39...
- Page 8 www.cypeurope.com PU-106_Manual-EN.indd 6 26/04/2011 12:50:53...
