Heatilator C40 Installation Manual
  1. Manuals
  2. Brands
  3. Heatilator Manuals
  4. Indoor Fireplace
  5. CONSTITUTION C-40
  6. Installation manual
Heatilator C40 Installation Manual

Heatilator C40 Installation Manual

Installation and fireplace setup epa certified woodburning fireplace
Hide thumbs Also See for C40:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE:
DO NOT discard this manual!
Model(s):
Tested and
Listed by
C
OMNI-Test Laboratories, Inc.
EPA CERTIFIED WOODBURNING
FIREPLACE
Installation and service of this fi replace should be
performed by qualifi ed personnel. Hearth & Home
Technologies recommends NFI certifi ed profes-
sionals, or technicians supervised by an
NFI certifi ed professional.
Heatilator • C40 Constitution • 480-2340 Installation Manual • Rev B 01-29-13
Installation Manual
Installation and Fireplace Setup
O-T L
Portland
Oregon USA
US
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• DO NOT overfi re. Overfi ring will void your
warranty.
• Comply with all minimum clearances to com-
bustibles as specifi ed. Failure to comply may
cause house fi re.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fi replace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may overfi re and generate poisonous
gases (i.e. carbon monoxide).
1
