Excalibur AL-1660-EDPB Operation Manual

Deluxe alarm & remote start w/ blade technology

Advertisement

AL-1660-EDPB
RS-360-EDPB
Deluxe Alarm & Remote Start w/ BLADE Technology
July 8, 2014
Operation Guide
Temporary cover. Color cover is in a separate file.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AL-1660-EDPB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Excalibur AL-1660-EDPB

  • Page 1 AL-1660-EDPB RS-360-EDPB Deluxe Alarm & Remote Start w/ BLADE Technology July 8, 2014 Operation Guide Temporary cover. Color cover is in a separate file.
  • Page 2: Table Of Contents

    Table Of Contents Transmitter Overview ��������������������������������������������������������������������������������������������������� 3 Transmitter Functions ��������������������������������������������������������������������������������������������������� 3 Low Battery/Low Temp Automatic Starting ��������������������������������������������������������������� 6 Other Remote Start Features ��������������������������������������������������������������������������������������� 6 Turbo Timer Feature ������������������������������������������������������������������������������������������������� 7 Pit-Stop Feature ������������������������������������������������������������������������������������������������������� 7 Manual Transmission Starting ���������������������������������������������������������������������������������� 7 Security System Features �������������������������������������������������������������������������������������������� 7 Last Door Arming ������������������������������������������������������������������������������������������������������...
  • Page 3: Transmitter Overview

    Transmitter Overview Transmitter part number: 1411-03 Call your dealer or visit www.caralarm.com to order “lock” replacement transmitters. button Battery replacement: “unlock” Remove the small screw from the button lower back case, and separate the “start” transmitter halves� Replace the button CR2032 battery (or with 2 CR2016 batteries) and reassemble the “trunk”...
  • Page 4 Transmitter Functions (cont’d) TRunK RELEASE / ChAnnEL 2: Press the “TRUNK” button for 3 seconds� • THE SYSTEM WILL DISARM / UNLOCK AND THE TRUNK WILL OPEN (IF EQUIPPED)� REmOTE START: Press and release the “START” button twice within 5 seconds� (see user feature #8 for additional options) •...
  • Page 5 Transmitter Functions (cont’d) ChAnnEL 4: Press and hold the “LOCK” & “TRUNK” buttons for 3 seconds� • YOUR SYSTEM WILL ACTIVATE THE CHANNEL 4 OUTPUT� ChAnnEL 5: Press and hold the “UNLOCK” & “START“ buttons for 3 seconds� • YOUR SYSTEM WILL ACTIVATE THE CHANNEL 5 OUTPUT�...
  • Page 6: Auxiliary Functions

    Transmitter Functions (cont’d) SEnSOR ByPASS: Press and release the “TRUNK” button within 5 seconds of locking/arming the alarm system� • THE SYSTEM WILL GIVE ONE CHIRP TO INDICATE THE SENSOR IS BYPASSED� NOTE: ALARM FUNCTIONS MUST BE ENABLED FOR THIS OPERATION LOW VOLTAGE/TEmP AuTO START: Press and release the “START”...
  • Page 7: Turbo Timer Feature

    Other Remote Start Features (cont’d) method 2 - With The Controller (Low Volt + Low Temp - 15 Degrees Only) • Within 5 seconds of pressing LOCK, press the START button. You will get one chirp to confirm. nOTE: When low temp start mode is activated, low voltage start is also activated� These features will operate once every two hours until the ignition key is turned “ON”�...
  • Page 8: Pre-Warn Detection

    Security System Features (cont’d) PRE-WARn DETECTiOn This system’s impact sensor (optional for the RS-360-EDPB) is designed, in addi- tion to detecting a full impact, to warn away potential violators when it detects a light impact to the vehicle� The system will respond by chirping the siren/horn 3 times and locking the doors�...
  • Page 9: Securecode

    using The Valet Switch (cont’d) SECuRECODE SecureCode allows you to customize the number of valet presses required to perform an emergency override. SecureCode has 2 stages with the first requiring 1-9 button valet presses and the second requiring 0-9 valet button presses. This gives you 99 possible combinations�...
  • Page 10: Anti-Carjacking Protection

    The Status Light (cont’d) REmOTE START DiAGnOSTiCS The remote start system can also indicate which zone caused the last remote start cycle to end� To see this indicator, place the system into alarm valet mode� Immedi- ately after the chirp, the status light will flash to indicate which zone violation occured. 1 FLASh: Run time expired�...
  • Page 11: Programming Transmitters

    Programming Transmitters Standard Programming: This method to program additional or replacement trans- mitters does not affect the Unauthorized Transmitter Alert (UTA) feature� Before you begin, have all transmitters which are to operate the system at hand� Step 1 Then, turn the ignition “on” (do not crank the engine)� Step 2 Within 5 seconds of Step 1, press the Valet Switch 5 times�...
  • Page 12: User Programmable Features

    (press “trunk” button to program) Steady Siren (press “start” button to program) - DEFAuLT (AL-1660-EDPB) This changes the BROWN wire’s audible output when the alarm is triggered� Steady siren must be selected when using a siren (other horn outputs stay at the Medium setting)�...
  • Page 13 user Programmable Features (cont’d) Feature #7 - unlock w/ Trunk Release (press “lock” button to program) - DEFAuLT (press “unlock” button to program) “2nd channel” is most commonly used for trunk release, in which case the alarm should also disarm. This feature, when on, configures the system to unlock/disarm when the 2nd channel is activated�...
  • Page 14 user Programmable Features (cont’d) Feature #13 - SecureCode DEFAuLT - 1 Press SecureCode is a unique patented feature which allows you to custom select the number of Valet Switch presses in two stages, instead of a single “1 press”, which would be required in order to perform an Emergency Override.
  • Page 15: Installer Programmable Features

    installer Programmable Features This group of Installer Programmable Features are all accessed as a group in the second level of features’ programming� These features have a direct affect upon the system’s operations related to the installation and vehicle type AnD ShOuLD OnLy BE ChAnGED By ThE inSTALLER!!! Feature #1 - Remote Start Activation From The WhiTE/BLuE Wire 1 pulse (press “lock”...
  • Page 16 installer Programmable Features (cont’d) Feature #5 - Light Relay Function Dome Light Output (press “lock” button to program) - DEFAuLT Start (press “unlock” button to program) ignition Output (press “trunk” button to program) Accessory Output (press “start” button to program) Status (press “lock”...
  • Page 17 When a BLADE is inserted, this feature auto- matically switches to the ADS protocol. Feature #13 - Alarm Functions (press “lock” button to program) - DEFAuLT (AL-1660-EDPB) (press “unlock” button to program) - DEFAuLT (RS-360-EDPB) This feature converts the system into a strictly Keyless Entry/Remote Start System by eliminating all antitheft alarm-oriented operations and features�...
  • Page 18 installer Programmable Features (cont’d) Feature #17 Low Temp Crank Extender 0ms (Off) (press “lock” button to program) 200ms (press “unlock” button to program) - DEFAuLT 300ms (press “trunk” button to program) 400ms (press “start” button to program) When the vehicle’s interior temperature is below freezing, this feature adds extra crank time to the base timing (see installer feature #7)�...
  • Page 19: Programmable Features Matrix

    User Feature Programming: Ignition on, off, press valet 5 times Lock Button Unlock button Trunk button Start button Lock + Unlock # Feature (Brake x 1) (Brake x 2) (Brake x 3) (Brake x 4) (Brake x 5) 1 Remote Start Run Time 10 min 5 min 15 min...
  • Page 20 Back Cover Color cover is in a separate file.
