Excalibur Gold eg-1400atv User Manual

Gold series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
GOLD SERIES
OWNER'S MANUAL
COPYRIGHT: OMEGA RESEARCH & DEVELOPMENT INC. 1997

Table Of Contents

Introduction ................................................................................................................................................. 4
TM
The Easy Valet
Switch ............................................................................................................................. 5
The Red LED Status Indicator ................................................................................................................... 5
Excalibur Gold Advanced System Features ........................................................................................... 6-7
Transmitter Button Operation ............................................................................................................ 9-10
Multiple Car Operation ...................................................................................................................... 10-11
Arming The System Using The Transmitter ......................................................................................... 1 1
Arming Bypass ........................................................................................................................................... 1 2
Silent Arming And Disarming .................................................................................................................. 1 2
Sensor Bypass ............................................................................................................................................. 1 2
Automatic Last Door Arming ............................................................................................................ 13-14
Automatic Rearming ................................................................................................................................. 1 4
Remote Valet Mode .................................................................................................................................. 1 4
Security System Armed And Activated ............................................................................................. 15-16
Disarming The Security System Using The Transmitter ............................................................... 16-17
Personal Coded Override - Disarming The Security System Without The Transmitter .................. 1 9
Remote Panic Feature ............................................................................................................................... 2 0
Optional Trunk Release And 3rd Channel Output ................................................................................ 2 1
Red LED Status Indicator ................................................................................................................... 21-23
Audible And Visual Indicators ............................................................................................................ 23-24
Prewarning Feature .................................................................................................................................... 2 4
Programmable Features ...................................................................................................................... 25-40
Programming Transmitters ................................................................................................................ 41-42
1400
Page - 3
ATV
This manual is written under the assumption that a power doorlock
interface is installed with your Vehicle Security System. The type of this
interface will vary from vehicle to vehicle, and in some instances may
involve optional components. Please note that this system has 25 Pro-
grammable Features (easily accessed by the vehicle owner) which allow
the customizing of its operations. The Programmable Features, and the
addition of optional sensors may affect the exact operations as de-
scribed in this guide, which reflects a typically-installed system with
factory-set conditions of the Programmable Features. This product was
designed for professional installation. As this system is capable of
utilizing an electronic siren or the vehicle's horn for its audible output,
Congratulations on the purchase of your new Excalibur Gold security system and on
joining over 8 million people worldwide who have trusted their vehicle's security to the
designers of Omega Research & Development, Inc. Your Excalibur Gold system combines
state-of-the-art security technology with practical, user-friendly convenience features. You
will have increased peace of mind knowing that your vehicle, and its contents, are protected.
The added convenience features will also enhance the enjoyment and satisfaction of the day-
to-day use of your vehicle. To learn how to operate your security system, please become
familiar with the following three principal user components: the Remote Transmitter, the Red
LED Status Indicator and the Valet Switch.
The Remote Transmitter: Each security system comes with two pre-learned transmitters,
but can learn up to 4 different transmitters. The transmitter has three buttons: one large button
at the top, near the LED* and two smaller buttons below. This system is pre-programmed,
through a built-in learning routine, to have the transmitter buttons work in the following
configuration:
The large upper button is used to arm, disarm and panic the security system.
The small center button may be used to operate the trunk release feature; or, in
conjunction with the large button, for silent arming or disarming of the system.
The small lower button is used, in conjunction with the large button, to operate remote
sensor bypass, and remote valet. Used alone it operates the 3rd Channel Output.
The remote transmitter's operation is explained in more detail on Pages 8-10.
* LED is the abbreviation for Light Emitting Diode, which is used as a visual indicator.
both forms are represented in the text.
Introduction
Page - 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Excalibur Gold eg-1400atv and is the answer not in the manual?

Questions and answers

Related Manuals for Excalibur Excalibur Gold eg-1400atv

Summary of Contents for Excalibur Excalibur Gold eg-1400atv

  • Page 1: Table Of Contents

    1400 This manual is written under the assumption that a power doorlock interface is installed with your Vehicle Security System. The type of this interface will vary from vehicle to vehicle, and in some instances may GOLD SERIES involve optional components. Please note that this system has 25 Pro- OWNER'S MANUAL grammable Features (easily accessed by the vehicle owner) which allow the customizing of its operations.

  • Page 2: The Red Led Status Indicator

    The Valet Switch: This switch is used to place the system into Valet Mode, which prevents Excalibur Gold Advanced System Features manual arming and any automatic system functions which may have been programmed to operate. The Valet Switch is also used, in conjunction with the ignition key, to perform an Automatic Transmitter Verification : Your Excalibur Gold vehicle security system is Override function, which will allow disarming the security system in the event the transmitter...

  • Page 3: Transmitter Button Operation

    Please note that certain conditions will affect the previously described system operations The Remote Transmitter - if the ignition switch is "on", the security system cannot be armed, but pressing and holding Transmitter Button Operation: The transmitter's three buttons individually control the the transmitter's Large Upper Button for 3 seconds will engage the Panic Feature.

  • Page 4: Automatic Last Door Arming

    Passive System Arming And Rearming your ignition key turned "on". Last Door Arming does not effect the operation or use of the transmitter to arm the system - if desired, the transmitter may still be used to arm the system at any time.

  • Page 5: Easy Valet Tm Mode

    indicate which zone triggered the system by flashing two to five times, pausing between In most cases the Valet Switch is behind the LED Status Light, as both may be mounted flashes. This violation code will continue to flash, even after disarming. The system can hold in a special combination holder.

  • Page 6: Red Led Status Indicator

    Optional 3rd Channel Output: This output's operation is the same as the trunk release your vehicle and keys with someone, you will now have the peace of mind of knowing that output except for the following items: Press the lower small transmitter button for 2 seconds only your transmitters will operate the security system and that no additional transmitters have to activate the 3rd channel output.

  • Page 7: Programming Features

    Programming Features period, then one chirp (or a short honk). You now have 8.5 seconds to initiate stage #2 of entering the Override Code. Momentarily press the Valet Switch Your vehicle security system has a total of 25 Features which may be programmed via the equal to the Override Code number programmed for stage #2.
  • Page 8 4) Starter Interrupt 90 Seconds After Ignition "Off" Or Disarming: Default OFF. button. The system will respond with a single siren chirp (or horn honk) to indicate Activating this Feature will cause the Starter Interrupt output to automatically en- that the Feature is ON. Pressing the small center button will turn this Feature OFF, gage 90 seconds after the ignition switch is turned "off", and also 90 seconds after with the system's response being two siren chirps (or horn honks).
  • Page 9 will respond with two siren chirps (or horn honks) to indicate that this Feature is OFF. being a single siren chirp (or horn honk). Pressing the large upper button will turn this Feature ON, with the system's response being a single siren chirp (or horn honk). 12) Confirmation Siren Chirps (Or Horn Honks) While In Valet Mode: Default OFF.
  • Page 10 To change the system from the default setting, follow Steps 1, 2, and 3 on Pages is now 45 seconds. Pressing the large upper button will return this Feature to the 3 second arming delay, with the system's response being a single siren chirp (or horn 25-26.

  • Page 11: Programming Transmitters

    Programming Transmitters 4)To learn the first transmitter code, press the large transmitter button, (which will arm/disarm/ panic the system), until you hear one long and one short siren chirp (or horn honk) to confirm Important! If Automatic Transmitter Verification (siren chirping or horn honking for that the code was learned.
