REMOTES: 3 Button/Green LED 433MHz Omega Part #103-03 Board # ET4E
REMOTE OPERATION:
Large Button- Press and release to arm/lock and disarm/unlock. Press and hold to activate panic.
Right Button- Hold for 3 seconds to activate 2
Left Button- Press and hold for 3 seconds to activate 3
without confirmation chirps. Press and release before disarming to disarm without confirmation chirps. Press and release after arming
to achieve sensor bypass. Press and release after disarming to achieve remote valet.
ZONE VIOLATION CODE: After remotely disarming the LED will flash one of the following codes if the alarm was activated while it was in
an armed state.
Flash 1X- System was activated from the current sensing feature.
Flash 2X- System was activated from the hood or trunk circuit wire.
Flash 3X- System was activated from the door circuit wire.
Flash 4X- System was activated from the auxiliary input.
CODING REMOTES: Unit must be in a disarmed state.
Step 1- Turn "on" the ignition.
Step 2- Press valet button 5 times and wait for a siren chirp.
Step 3 –Press the large button, unit will respond with 1 siren chirp. Press the right button, unit will respond with 2 siren chirps. Press
left button, unit will respond with 3 siren chirps. (Repeat as needed.)
1) Unit has 12-pin harness.
nd
2) Unit has 2
and 3
3) Unit has 4-pin auxiliary port.
4) Unit has 4 pin door lock plug.
5) Unit has back up battery port for use with a 9 volt battery.
6) Unit has 4 dip switches for features. (See feature section)
7) Unit has plug in valet button.
8) Unit includes starter interrupt socket and relay.
9) AU-84TA shock sensor included.
Turn ignition "on" then "off"- Press valet button 5 times and wait for response chirp- Press valet button equal to the feature # you wish to
change— Pressing Large button turns feature "on"— Pressing small button turns feature "off".
FEATURE#
Feature#1Ignition Activated Door Locks
Feature#2 Open Door By-Pass To Feature 1
Feature#3 Parking Light Duration
Feature#4 90 Second Rearming
Feature#5 Disarm Alarm Upon Trunk Release
Feature#6 Door Lock Pulse Duration
Feature#7 Arming Delay
Feature#8 Chirp Confirmation
DIP SWITCHES
Switch #1- Hijack
Switch #2- Last Door Arming
Switch #3- Doors Lock With Last Door Arming
Switch #4- Current Sensing
AL-1000 SX
nd
channel output.
rd
channel outputs in the main harness.
Programmable Features
Total System Reset
Must be reset at the factory.
rd
channel output. Press and release within 3 seconds before arming to Arm
NOTES
DEFAULT
LARGE BUTTON
ON
ON
ON
ON
60 sec.
60 sec.
ON
ON
ON
ON
.8 sec.
.8 sec.
3 sec.
3 sec.
ON
ON
DEFAULT
UP
OFF
ON
ON
ON
ON
ON
ON
ON
SMALL BUTTON
OFF
OFF
30 sec.
OFF
OFF
3 sec.
45 sec.
OFF
DOWN
OFF
OFF
OFF
OFF
