Altronix Sav4D Installation Manual page 12

1.20"
(31mm)
1.40"
(36mm)
5.10"
(130mm)
5.10"
(130mm)
3.25"
(83mm)
Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: info@altronix.com, Made in U.S.A.
IISAV4D/SAV9D/SAV18D/SAV182D/SAV36D
- 12 -
Enclosure Dimensions for Sav182D and Sav36D:
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.55mm)
1.40"
(36mm) (123mm)
0.75"
(19mm)
13.0"
(330mm)
1.0"
(25mm)
1.0"
(25mm)
4.85"
(123mm)
12.5"
(318mm)
11.0"
(279mm)
10.5"
(267mm)
H14N
4.85" 1.40"
(36mm)
1.20"
(31mm)
0.75"
(19mm)
0.9375"
(24mm)
0.9375"
(24mm)
1.0"
(25mm)
1.0"
(25mm)
3.25"
(83mm)
1.20"
(31mm)
1.40"
(36mm)
5.10"
(130mm)
6.5625"
(167mm)
3.25"
(83mm)
3.25"
(83mm)
MEMBER
Sav4/9/18/182/36D
