4.1 Lights

(Normal power-up)
Normal Mode
Both the READY

4.2 Buttons

PAUSE ,
The three buttons,
operational mode. The printer operates in one of the following modes:
Normal:
Normal printer functions. See Section 4.3.
Express Setup:
Allows quick access to the most common printer settings, (Sensor Type, Media Type, and Option Control. See
Section 4.4.
Printer Setup:
Allows changes to the printer's operational settings. See Section 4.5.
Calibration:
Allows the 'calibration' of the media being used for the correct sensing of the top of form. See Section 4.7.
18
Solid On: Indicates the printer is in the 'Paused' state
STOP
Flashing: (When using the Peel & Present Option) Indicates
a label is presented to the operator.
ERROR Indicates a top of form or mechanical error has occurred
Solid On: Indicates the printer is on and ready for printing
READY
Flashing: Indicates the printer is receiving data from the host
STOP Lights will be on during power-up initialization and a warm reset.
and
FEED , and
CANCEL perform different functions based on the printer's
