EarthWay 2170T Tow Assembly And Operating Instructions Manual

PLEASE CALL IF YOU ARE MISSING ANY PARTS, HAVE ANY DIFFICULTY IN ASSEMBLY, OR HAVE ANY QUES-
TIONS REGARDING THE SAFE OPERATION OF THIS SPREADER.
THIS MODEL INCLUDES LIFETIME TECHNICAL SUPPORT
SUPPORT HOT LINE: 574-848-7491 or 800-294-0671 EMAIL: support@earthway.com
HELPFUL HINTS:
If your spreader does not spread evenly, be sure the FRONT on the gear box points in the correct direction (toward the tow hitch).
The impeller must turn clockwise. Reversing the gearbox will cause the impeller to turn counter clockwise. Clean the impeller
plate after each use. Fertilizer stuck on the impeller blades will cause uneven spreading.
Your spreader is designed to be towed at three miles per hour, which is a brisk walking speed. Slower or faster speeds will change
the spread patterns. Wet fertilizer will also change the spread pattern and flow rate.
Clean your spreader thoroughly after each use. Wash between the shut off plate and bottom of the hopper.
Gears are permanently lubricated at the factory. Do not open the gearbox or dirt may enter.
When using Rock Salt remove the agitator to prevent damage to the gearbox and remove salt from the hopper daily. Rock Salt will
reconstitute back into a solid block over night with humidity.
1.
Remove and identify loose parts from carton.
READ THE DIRECTIONS BEFORE ASSEMBLY
ASSEMBLY and OPERATING INSTRUCTIONS
EarthWay
for
MODEL 2170T Tow
Broadcast Spreader
2.
Position hopper upside down and install frame using
(4) 1/4 – 20 x 1 1/2" Pan Head Phillips screws.
R S
OCK ALT OR
ARE NOT RECOMMENDED FOR USE
IN THIS SPREADER
R
EMOVE AGITATOR WHEN USING
E -N-S
V
R . 5-06
EV
P
OWDERED LIME
I M .
CE ELT
PAGE 1
®
