Safety
s) Secure the workpiece. A workpiece supported
by pipe holders is held more secure than by
hand.
t) Always wait until the machine has come to
a complete stop before placing it down. The
tool insert can jam and lead to loss of control
over the power tool.
u) Never use the machine with a damaged cable.
Do not touch the damaged cable and pull
the mains plug when the cable is damaged
while working. Damaged cables increase the
risk of an electric shock.
Additional specific safety rules
The pipe saw must never be used in the following
cases, if:
• There is water or another liquid, explosive gases
or poisonous chemicals inside the pipe to be cut.
• The power switch is faulty.
• The power cable is faulty,
• The blade is bent.
• The blade is blunt or in poor condition.
• The plastic components are cracked or have parts
missing.
• The gripper unit is not properly tightened around
the pipe or if it is warped.
• The blade guard cover or moving blade guard
has been damaged or removed from the machine.
• The locking mechanisms do not work properly
(UNLOCK-button).
• The pipe saw has become wet.
When using the pipe saw, the following factors
must always be taken into consideration:
• Support tubes to minimise the risk of blade
pinching.
• Ensure that the pipe to be cut is empty.
• Ensure that the blade is correctly installed.
• Ensure that the diameter and thickness of the
blade are suitable for the pipe saw and that the
blade is suitable for the rpm-range of the machine.
• Never use sideways force to stop the blade, always
allow the blade to stop freely.
• Check the attachments of the blade guards.
• Never use excessive force when using the pipe
saw.
• Never use the pipe saw to lift the pipe while it is
still attached to the pipe.
• Avoid overloading the electric motor.
• Always follow the safety and operating instructions
and current regulations.

Functional Description

Read all safety warnings and all
instructions. Failure to follow the warnings
and instructions may result in electric
shock, fire and/or serious injury.
Intended Use
PipeCut 200:
The PipeCut 200 pipe saw is intended for use as a
pipe fitter's tool at the installation site. The PipeCut
200 pipe saw can only be used to cut round pipes,
with a diameter of 15-200 mm (0,6"-8") and a
maximum wall thickness of 8 mm with steel and
other ferrous and non-ferrous materials and 14 mm
with plastics. The PipeCut 200 pipe saw can be
used to cut all normal pipe materials, such as steel,
stainless steel, cast iron, copper, aluminium and
plastic. PipeCut 200 pipe saw is intended for short,
intermittent use. The machine may be loaded for
2,5 minutes during a 10-minute period (S3 25 %).
PipeCut 200 pipe saw is not intended for use in
industrial production. Use pipe holders to support
pipe.

Product Features

While reading the operating instructions, unfold the
graphics page for the machine and leave it open.
This page is folded under the cover of this manual
(page 3). The following numbering of the product
features refers to this illustration.
Figure A
1. UNLOCK button
2. Power switch
3. Power-switch locking lever
4. Blade-guard cover
5. Blade-guard finger screw
6. Moving blade-guard
7. Edge of moving blade-guard
8. Braking wheels
9. Adjusting wheel
10.Operating handle
11.Spindle-lock button
12.Blade-guard finger screw
13.Motor unit
14.Rating plate
15.Overload protection
16.Gripper unit
17.Gripper adjustment handle
