eXact PipeCut+Bevel 170E Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PipeCut+Bevel 170E
System
Exact Tools Oy
Särkiniementie 5 B 64
FI-00210 Helsinki
Finland
Tel +358 9 4366750
Fax +358 9 43667550
Operating Instructions
5-16
EN
exact @exacttools.com
www.exacttools.com
patents: US 7,257,895, JP 4010941, EP 1301311, FI 108927, KR 10-0634113

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PipeCut+Bevel 170E and is the answer not in the manual?

Questions and answers

Related Manuals for eXact PipeCut+Bevel 170E

Summary of Contents for eXact PipeCut+Bevel 170E

  • Page 1 PipeCut+Bevel 170E System Exact Tools Oy Särkiniementie 5 B 64 FI-00210 Helsinki Finland Tel +358 9 4366750 Fax +358 9 43667550 Operating Instructions 5-16 exact @exacttools.com www.exacttools.com patents: US 7,257,895, JP 4010941, EP 1301311, FI 108927, KR 10-0634113...
  • Page 2 Use only Exact PipeCut+Bevel Diamond discs or other Exact Diamond discs for this pipesaw. Pre-adjust the blade speed to 6. Exact PipeCut+Bevel 170E System can be used for cut or cut and beveling cast iron pipes and certain plastic pipes. Do not use it with other materials!
  • Page 4 EN55014-1, EN 55014-2, EN61000-3-2, EN61000-3-3 according to the provisions of the directives 2004/108/EC, 2006/42/EC. For more information, please contact Exact Tools at the following address. The technical fi le is available at the address underneath. The person authorized to compile the technical fi le: Mika Priha, R&D manager (mika.priha@exacttools.com)

  • Page 5: Table Of Contents

    Contents english The original language of this manual is English Contents 6. Technical data 6. Package contents Safety 7. Safety instructions Operation 10. Functional description 10. Product features 11. Before operating the tool 11. Connection to the mains power supply 11.

  • Page 6: Technical Data

    Also store this instruction book somewhere accessible to everyone using the pipe saw. In addition to these instructions, always follow the offi cial work, health and safety regulations. The Exact PipeCut+Bevel 170E is meant for professional use only. Technical data...

  • Page 7: Package Contents

    Package contents: Please check the package contains the following items: 1. Pipecutting System case 2. Exact PipeCut+Bevel 170E pipe saw 3. Cutting supports 4x4. 4. Operating instructions 5. Hex socket key 5 mm and 2 mm fi tted to the machine 6.

  • Page 8: Safety

    Safety english General power tool safety attached to a rotating part of the power tool may result in personal injury. warnings e) Do not overreach. Keep proper footing and balance at all times. This enables better control of WARNING: Read all safety warnings and all the power tool in unexpected situations.

  • Page 9: Safety Instructions

    Safety english c) Adjust the cutting depth to the thickness of the Kickback is the result of saw misuse and/or incorrect work piece. Less than a full tooth of the blade teeth operating procedures or conditions and can be avoided should be visible below the work piece.

  • Page 10: Functional Description

    The machine may be loaded for 2,5 minutes during a 10-minute period (S3 25 %). The PipeCut+Bevel 170E pipe saw is not intended for use in industrial production. Use pipe Exact pipe supports to support the pipe.

  • Page 11: Before Operating The Tool

    Operation english Exact PipeCut+Bevel Fig C 170E pipecutting system operating instructions Before operating the tool Ensure that the motor unit is in the upright position. The yellow mark of the UNLOCK button is visible. Check that the blade is correctly fi tted, in good condition and suitable for the material to be cut.
  • Page 12 Operation english Pre-setting the correct bevel depth to the saw Fig E You can cut OD 15 -170 mm cast iron and plastic pipes or you can cut + bevel those pipes OD 50 - 170 mm. There is an adjustment lever in the gripping unit of the saw for to pre-set the correct depth for the bevel (Figure A 18).
  • Page 13 Overload protection and spin-speed regulator There is a spin-speed regulator in Exact Cut+Bevel 170E A suitable spin speed is selected, determined by the material to be sawed / beveled. There is also an automatic overload protection in the regulator.
  • Page 14 Operation english For this reason the result may vary, and the Fig N cut may turn to left or right (misalignment of the cut’s starting and ending point) (Fig. M). The pipe saw gripper has one adjustable wheel (Fig. A/9) which be used for improving the quality of the cut and for reducing the misalignment.
  • Page 15 When you notice rubbish depositories or to the dealer that the disc is blunt, do not continue sawing when buying a new product. with it. Don’t use normal saw blade with Exact Cut+Bevel 170E saw. Guarantee Use only diamond discs.
  • Page 16 Tips english Note: The Exact PipeCut Saw is to be shipped Always keep the motor unit in the upright to the Authorized Warranty Repair Center freight position. The yellow mark of the unlock button is prepaid. If the Exact PipeCut Saw is repaired then visible.
