Safety
• The power switch is faulty.
• The power cable is faulty,
• The blade is bent.
• The blade is blunt or in poor condition.
• The plastic components are cracked or have parts
missing.
• The gripper unit is not properly tightened around the
pipe or if it is warped.
• The blade guard cover or moving blade guard has
been damaged or removed from the machine.
• The locking mechanisms do not work properly
(UNLOCK-button).
• The pipe saw has become wet.
When using the pipe saw, the following factors
must always be taken into consideration:
• Support tubes to minimise the risk of blade
pinching.
• Ensure that the pipe to be cut is empty.
• Ensure that the blade is correctly installed.
• Ensure that the diameter and thickness of the blade
are suitable for the pipe saw and that the blade is
suitable for the rpm-range of the machine.
• Never use sideways force to stop the blade, always
allow the blade to stop freely.
• Check the attachments of the blade guards.
• Never use excessive force when using the pipe
saw.
• Never use the pipe saw to lift the pipe while it is still
attached to the pipe.
• Avoid overloading the electric motor.
• Always follow the safety and operating instructions
and current regulations.

Functional Description

Read all safety warnings and all
instructions.
Failure to follow the warnings and
instructions may result in electric shock, fi re
and/or serious injury.
Intended Use
PipeCut+Bevel 170E:
The PipeCut+Bevel 170E pipe saw is intended
for use as a pipe fi tter's tool at the installation
site. The PipeCut+Bevel 170E pipe saw can
only be used to cut or to cut and bevel round
pipes, which are made of cast iron or plastics
with a diameter of 15-170 mm (0,6"-6") and wall
thickness 8 mm (0,31") with cast iron and 14 mm
(0,55") with plastics. ThePipeCut+Bevel 170E
pipe saw can be used only to cut or to cut and
bevel cast iron and certain plastic materials.
The PipeCut+Bevel 170E pipe saw is intended
for short, intermittent use. The machine may be
loaded for 2,5 minutes during a 10-minute period
(S3 25 %). The PipeCut+Bevel 170E pipe saw is
not intended for use in industrial production. Use
pipe Exact pipe supports to support the pipe.

Product Features

While reading the operating instructions, unfold
the graphics page for the machine and leave it
open. This page is folded under the cover of this
manual (page 3). The following numbering of the
product features refers to this illustration.
Figure A.
1. UNLOCK button
2. Power switch
3. Power-switch locking lever
4. Blade-guard cover
5. Moving blade-guard
6. Edge of moving blade-guard
7. Braking wheels
8. Adjusting wheel
9. Operating handle
10. Blade-guard screw
11. Spindle-lock button
12. Motor unit
13. Blade key and (key for the adjusting
wheel)
14. Rating plate
15. Overload protection or rpm regulator
16. Gripper unit
17. Gripper adjustment handle
18. Bevel depth adjustment
10
