- Page 1 English Operating Instructions Pipecut 280 Pro Series / 360 Pro Series / 450 Pro Series The instructions are translated from original manual written in Finnish language available on web-site: exacttools.com/manuals Patents: US 7,257,895, JP 4010941, EP 1301311, FI 108927, KR 10-0634113...
- Page 2 Declaration of Conformity WE declare under our sole responsibility that the pipe cutting machines Exact PipeCut 280 Pro Series / 360 Pro Series / 450 Pro Series Described under” Technical Data” are in conformity with the following standards or standardization documents:...
- Page 3 English FIGURE A Unlocking switch Power switch Power switch locking lever (in front of the switch) Blade guard cover Overload indicator light Moving blade-guard Adjusting screws Laser pointer box Adjusting wheel 10 Handle 11 Disc protection screw 12 Lock pin 13 Plate 14 Motor unit 15 Rotation speed control...
-
Page 4: Table Of Contents
Sawing around a pipe Overload protection and rotation speed control Improving possible misalignment of the cut Exact PipeCut 280 Pro Series / 360 Pro Series / 450 Pro Series cutting result adjustment Installing and changing the saw blade or Diamond X Disc... - Page 5 NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in property damage. Denotes risk of electric shock. Exact PipeCut 280 Pro Series / 360 Pro Series pipe saws models Voltage 1 230 V– 240 V / 50–60 Hz tai 100 V–120 V 50–60Hz Power 2500 W–...
-
Page 6: Information
This may significantly increase the exposure level over the total working period. Exact PipeCut 280 Pro Series / 360 Pro Series / 450 Pro Series pipe cutting systems Package Contents Please check that the package contains the following items:... -
Page 7: Safety
Safety English General power tool safety instructions b). Use personal protective equipment. Always wear eye protection. Protective equipment such as dust WARNING: Read all safety warnings and all mask, non-skid safety shoes, hard hat, or hearing instructions. Failure to follow the warnings and protection used for appropriate conditions will instructions may result in electric shock, fire and/or reduce personal injuries. - Page 8 PipeCut 280 Pro Series / 360 Pro Series power tool for operations different from those PipeCut 280 Pro Series / 360 Pro Series / 450 Pro intended could result in a hazardous situation. Series pipe saw is intended for use as a pip fitter’s h) Keep handles and other gripping surfaces dry and tool at the Job site.
-
Page 9: Operation
Operation English Exact PipeCut 280 Pro Series FIGURE B /1 / 360 Pro Series / 450 Pro Series pipe cutting system operation instructions Before operation the tool Ensure that motor unit is in the upright position. The yellow mark of the UNLOCK SWITCH is visible. -
Page 10: Piercing The Pipe Wall
Operation English Piercing the pipe wall FIGURE Grip the gripper firmly with your right hand and place your left foot on top of the pipe approximately 50 cm from the pipe saw. Turn the saw until it leans slightly forward (Figure I). When starting the motor, first of all release the power-switch locking lever (Fig G/1) and push the power switch all the way down (Fig G/2). -
Page 11: Improving Possible Misalignment Of The Cut
Operation English Overload protector and rotation speed control FIGURE The saw has a two-speed rotation speed control (Fig A/15). When sawing stainless or acid-proof steel use the lower rotation speed l. When sawing other materials use the faster rotation speed ll. The saw also has an overload protector which switches the power off automatically in an overload situation. - Page 12 6. Tighten the locking screws of the adjustment plate very tightly. CAUTION! The motion sensor located in the back of the adjustment plate does not report the exact size to adjust. The sensor shows only the direction of adjustment and the category of magnitude.
- Page 13 Operation English FIGURE M /c...
-
Page 14: Maintenance And Servicing Instructions
Operation English CAUTION! If a part of the engine is regulated by the Maintenance and servicing instructions laser, the gripping device must be attached to the pipe Remove the power plug from the socket before with normal tension. Thus, you can be sure that the servicing or cleaning the pipe saw. - Page 15 The cutting process is divided into two stages: first you PipeCut Saw at no charge. need to cut the pipe wall, then cut around the pipe The Exact Tools Warranty Term is for 12 months from Do not overload the saw while working without date of purchase.
-
Page 16: Cutting Depths
Too tightened blade/disc Extra equipment 280 – 360 – 450 PS Blade/Discs Exact TCT: Suitable for cutting steel and all kinds of plastic pipe material Exact Cermet: Suitable for cutting stainless steel and acid proof materials, steel, copper, aluminium and all kind of plastic pipe materials. - Page 17 Extra equipment, cutting depths русский Max. pipe wall thicknesses in different pipe materials, which can be cut by Exact 280 Pro Series and Exact 360 Pro Series European model 230V / 2500W Steel pipes Max.pipe wall thickness 20 mm / 0.78”...
