Specifications and Features

Operating frequencies:
Frequency Selection:
Channel Separation:
RF Power output:
Pilot tone:
Frequency stability:
Deviation:
Spurious radiation:
Equivalent input noise:
Input level:
Input impedance:
Input limiter:
(Note: The dual envelope "soft" limiter provides exceptionally good handling of transients using variable attack and release time constraints.)
Gain control range:
Modulation indicators:
Low frequency roll-off:
Audio frequency response
(overall system):
(Note: The transmitter is deliberately rolled off at 70Hz in the LM tramsmitter to reduce transmission of the lower frequency noise.)
Controls:
Audio Input Jack:
Antenna:
Battery:
Battery Life:
Weight:
Dimensions:
Emission Designator:
Specifications subject to change without notice.
The FCC requires that the following statement be included in this manual:
This device complies with FCC radiation exposure limits as set forth for an uncontrolled environment. This device
should be installed and operated so that its antenna(s) are not co-located or operating in conjunction with any
other antenna or transmitter.
Rio Rancho, NM
Block 21 537.600 - 563.100
Block 22 563.200 - 588.700
Block 23 588.800 - 607.900 and 614.100 - 614.300
Block 24 614.400 - 639.900
Block 25 640.000 - 665.500
Block 26 665.600 - 691.100
Block 27 691.200 - 716.700
Block 28 716.800 - 742.300
Block 29 742.400 - 767.900
256 frequencies in 100 kHz steps
100 kHz
Greater than 50 mW
25 to 32 kHz frequency; 5 kHz deviation (400 Series only)
± 0.002%
± 75 kHz max. (400 Series only)
60 dB below carrier
–120 dBV, A-weighted
Nominal 2 mV to 300 mV, before limiting.
Greater than 1V maximum, with limiting.
2k Ohm
Dual envelope, >30 dB range
43 dB; semi-log rotary control
Dual bicolor LEDs indicate modulation of -20, -10, 0, +10 dB referenced to full modulation.
LM: –12 dB/octave; 70Hz
IM: –12 dB/octave; 35Hz
LM: 90 Hz to 20 kHz (+/- 1 dB) with the 70Hz low frequency roll-off filter.
IM: 40 Hz to 20 kHz (+/- 1 dB)
2 position "OFF-ON" slide switch for noiseless turn on/turn off operation.
Front panel audio gain control.
Rotary switches on side panel adjust transmitter frequency.
Switchcraft 5 pin locking (TA5F)
Galvanized steel, flexible wire.
Precision compartment auto-adjusts to accept any known alkaline 9 volt battery.
6 hours (alkaline); 13 hours continuous (lithium)
6.3 ozs. including battery
3.1 x 2.4 x .75 inches
180KF3E
Frequency-Agile UHF Belt-Pack Transmitter
