- Page 1 INSTRUCTION MANUAL Handheld Transmitter Digital Hybrid Wireless Technology ® US Patent 7.225.135 Fill in for your records: Serial Number: Purchase Date: Rio Rancho, NM, USA www.lectrosonics.com...
- Page 2 LECTROSONICS, INC.
-
Page 3: Table Of Contents
Hand Held Transmitter Table of Contents General Technical Description ..........4 Introduction ................4 Digital Signal Processor ............4 Compatibility Modes .............. 4 Digital Hybrid Technology ............. 4 Wide Deviation ..............4 Pilot Tone Squelch ..............5 Input Gain Range and Limiter ..........5 Long Battery Life .............. -
Page 4: General Technical Description
FM systems, the Digital Hybrid has elimi- the flexibility of digital signal processing, however, the nated the analog compandor and its artifacts. transmitter is also able to operate with Lectrosonics 200 Series, Lectrosonics 100 Series, IFB and certain Wide Deviation non-Lectrosonics analog receivers in special compat- ibility modes. -
Page 5: Pilot Tone Squelch
HH: those with a 1.25” x 28 thread pitch and three ing short term dynamics. contact rings. Dynamic and condenser microphone... -
Page 6: Capsule And Battery Installation
Do not touch the contacts between the mic capsule compartment. and transmitter body. When necessary, the contacts can be cleaned with a cotton swab and alcohol. To remove the batteries, pull the eject lever outward. The battery tips will move outward, making them easier to grasp. LECTROSONICS, INC. -
Page 7: Control Panel
Hand Held Transmitter Control Panel Powering Off Six membrane switches on the control panel are used Press and hold the Power Button for several seconds to set up the transmitter by navigating the menus on and observe the countdown on the LCD. The count- the LCD and selecting the desired values. -
Page 8: Battery Condition
If you use rechargeable batteries in IMPORTANT: See the section About Setting the HH, we recommend trying fully charged batteries Audio Gain on page 10 for details. first, noting the length of time that the batteries will run the unit, and in the future using somewhat less than Freq. - Page 9 Hand Held Transmitter Compat Backlgt The HH can be used with earlier Lectrosonics wireless The LCD includes a backlight that illuminates the and IFB systems and systems from other manufactur- display for easier viewing in dim lighting conditions. It ers by selecting the correct Compatibility Mode. The is set to come on when any button on the control panel receiver must be set to the same mode.
-
Page 10: About Setting Audio Gain
(see Powering On and Off, and the Standby Mode on page 7). NOTE: Full modulation is achieved when the -20 LED first turns red. 30 dB of clean limiting is available above this point. LECTROSONICS, INC. -
Page 11: Main Window Displays For Mute And Talkback Functions
Hand Held Transmitter Main Window Displays for Mute and Talkback Functions The function of the Side Button is displayed in the LCD Main Window. MUTE 623.400 623.400 623.400 No Function Talkback Audio Mute When the Side Button is pressed, the function will be active and the LCD will display an indication. -
Page 12: Troubleshooting
4) Sound system or recorder input level is turned down. DISTORTED SOUND 1) HH Audio Gain set too high. Speak or sing into the HH and check the Audio Level LEDs, Audio Level bar graph in the HH LCD and corresponding indicators on the receiver. -
Page 13: Specifications
RF exposure guidelines when used with the Lectrosonics accessories supplied or designated for this product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. Contact Lectrosonics if you have any questions or need more information about RF exposure using this product.. -
Page 14: Service And Repair
There are no adjustments inside that will make a malfunctioning unit start working. LECTROSONICS’ Service Department is equipped and staffed to quickly repair your equipment. In-warranty repairs are made at no charge in accordance with the terms of the warranty. Out-of-warranty repairs are charged at a mod- est flat rate plus parts and shipping. - Page 15 Hand Held Transmitter Rio Rancho, NM...
-
Page 16: Limited One Year Warranty
This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
