Installation
WARNING: Hard drives require careful handling, especially when
being transported. If you are not careful with your hard disk, lost data
may result. Always handle your hard drive and storage device with
caution.
Hardware Installation
1.
Plug the universal power adapter into a wall power outlet and into
the DC In connector on the duplicator dock.
2.
If using a SATA hard drive as the source disk. gently slide the
hard drive into the 7+15 SATA connector labeled Source-1 on the
duplicator dock. Skip to step 6.
3.
If using an IDE hard drive as the source disk, connect the IDE ribbon
cable (included) to the 40-pin connector labeled Source-2. The
connector is keyed to fit only one way.
4.
Connect the LP4 molex cable (included) into the 4-pin connector
next to the 40-pin IDE connector. The connector is keyed to fit only
one way.
3
