- Page 1 USBDOCK2 Instruction Manual USB Docking Station Universal USB 2.0 Laptop Docking Station with Audio and Ethernet Manual Revision:09/13/2010 For the most up-to-date information, please visit www.startech.com...
- Page 2 Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.
-
Page 3: Table Of Contents
Table of Contents Introduction ............... 1 Packaging Contents.............. 1 System Requirements ............1 Rear View ................2 Side View 1 ................2 Side View 2 ................2 Installation ..............3 Hardware Installation ............3 Verify Installation ..............3 Specifications ............4 Technical Support ............. -
Page 4: Introduction
10/100Mbps RJ45 Ethernet, 3.5mm mini-jack audio connectors for headphones and microphones and four additional USB 2.0 ports. The USBDOCK2 makes it easy to plug and unplug your devices when moving your laptop around. Simply plug in one cable to connect to multiple peripherals at your desk or work station. -
Page 5: Rear View
Rear View Side View 1 Side View 2... -
Page 6: Installation
Installation Hardware Installation 1. Insert the included Installation CD into the computer’s CD/DVD drive. 2. Make sure no other devices are connected to the docking station. 3. Connect the included USB cable from the USB type B “Up” port on the docking station to an available USB port on the computer system. -
Page 7: Specifications
Specifications Bus Interface USB 2.0 Ethernet: Moschip MCS7830 Chipset ID Audio: C-Media CM108 1 x RJ45 Ethernet female 2 x 3.5mm mini-jack female Connectors 4 x USB type A female 1 x USB type B female 1 x DC Power 1 x RJ45 Link LEDs 1 x RJ45 Speed/Activity... -
Page 8: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech. com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,... - Page 9 StarTech.com has been making “hard-to-find easy” since 1985, providing high quality solutions to a diverse IT and A/V customer base that spans many channels, including government, education and industrial facilities to name just a few. We offer an unmatched selection of computer parts, cables, A/V products,...
