E5CN

COMMUNICATIONS SPECIFICATIONS

Transmission path connection
Communications method
Synchronization method
Baud rate
Transmission code
Data bit length
Stop bit length
Error detection
Flow control
Interface
Retry function
Communications buffer
Note: The baud rate, data bit length, stop bit length, or vertical parity can be individually set using the communications setting level.


CURRENT TRANSFORMER (SOLD SEPARATELY) RATINGS
Dielectric strength
Vibration resistance
Weight g
Accessories (E54-CT3 only) ( y)


HEATER BURNOUT ALARM SPECIFICATIONS
Max. heater current
Input current readout accuracy
Heater burnout alarm setting range
Min. detection ON time
Note: 1. When heater burnout is detected on a 3-phase heater, use the K2CU-F
2. When the set value is "00 A," the heater burnout alarm will always be OFF. When the set value is "50.0 A," the heater burnout
alarm will always be ON.
3. When the control output ON time is less than 190 ms, heater burnout detection and heater current measurement will not be
carried out.
Multiple points
RS-485 (two-wire, half duplex)
Start-stop synchronization
1,200/2,400/4,800/9,600/19,200 bps
ASCII
7 or 8 bits
1 or 2 bits
Vertical parity (none, even, odd)
Frame check sequence (FCS): with SYSMAC WAY
Block check character (BCC): with CompoWay/F
Not available
RS-485
Not available
40 bytes
1,000 VAC (1 min)
2
50 Hz 98 m/s
E54-CT1 Approx. 11.5 g
E54-CT3 Approx. 50 g
Armature 2
Plug 2
Single-phase AC: 50 A (See Note 1.)
±5%FS±1 digit max.
0.0 to 50.0 A (0.1 A units) (See Note 2.)
190 ms (See Note 3.)

A- GS (with gate input terminal).
