A
D – 500-
PPeNDIX
Page 32
R
S
SeRIeS
ACK
PeCIFICATIONS
Pins
Old API Specification
1
Chassis Ground
2
Output +4dB Hot
3
Output -2 Hot
4
Output Cold
5
A- Ground
6
Stereo Link
7
Input -2 Cold
8
Input +4dB Cold
9
Input -2 Hot
10
Input +4dB Hot
11
Gain Adjustment
12
+16VDC Supply
13
Power Ground – 0V ref
14
-16VDC Supply
15
+48VDC Phantom
Current Use In Market
Chassis Ground
Output +4dB Hot
- - -
Output Cold
A- Ground
Stereo Link
- - -
Input +4dB Cold
- - -
Input +4dB Hot
- - -
+16VDC Supply
Power Ground – 0V ref
-16VDC Supply
+48VDC Phantom
XL-Desk – Owner's Manual
