Option DIP Switches

The rear panel of XL-Desk has 12 DIP switches that can be used to set various functions of the desk. As you face the rear
panel of XL-Desk, the left-hand block of 6 DIP switches are options 1-6, the second block of 1-6 are options 7-12.
Switch No
1
2
3
4
5
6
7
8
9
10
11
12
NOTE: Do not switch to Programming Mode unless under instruction from an SSL engineer;
THE DESK WILL NOT FUNCTION AS EXPECTED IN THIS MODE.
Page 28
DIP SWITCH 1 - 12
ON
1 2 3 4 5 6
Sw.1
Switches are shown
in the UP position
Function
Meter Scaling
Talkback A
Talkback A
Talkback B
Talkback B
Unused
MINI 2 Speaker Set
Unused
Unused
Unused
Bargraph Test Mode
Programming Mode
ON
1 2 3 4 5 6
Sw.12
↑
Up
+24dBu
Sum
Momentary
Sum
Momentary
-
Stereo
-
-
-
Normal
Normal
↓
Down
+18dBu
Replace
Latching
Replace
Latching
-
Mono
-
-
-
Enabled
Enabled
