Using 500-series Rack Slots 9-16 with Microphone Preamplifiers

You may already own 500-series microphone preamplifier modules and
wish to use these with XL-Desk. You can fill 500-series rack slots 9-16
with microphone preamplifier modules and use them by doing the
following:
1) Plug the microphone(s) into the microphone preamplifier
module(s). If it does not have a front panel XLR then connect via
XL-Desk's rear panel connector labelled 500 SLOT IN 9-16.
2) Press the channel's 500 button. This will bring the signal into the
channel (presuming that the rear connector labelled 500 SLOT OUT
9-16 is connected to 500 RETURN 9-16).
3) Use the channel direct outputs to record signal into the DAW.
XL-Desk – Owner's Manual
'500' Preamplifiers
500 SLOT IN 9 - 16
500 SLOT OUT 9 - 16
