The following table identifies the I/O components in the server and points to
instructions for servicing them.
I/O Components (Sun SPARC Enterprise T5120 Servers)
TABLE:
Item FRU
1 Top cover
2 Hard drive cage and
hard drive backplane
3 Left control panel light
pipe assembly
4 Hard drives
5 DVD/USB module
6 Right control panel light
pipe assembly
Replacement Instructions
"Remove the Top Cover"
on page 67
"Install the Top Cover"
on page 175
"Servicing the Hard
Drive Cage" on page 146
"Servicing the Hard
Drive Backplane" on
page 152
"Servicing Front Control
Panel Light Pipe
Assemblies" on page 156
"Servicing Hard Drives"
on page 69
"Servicing DVD/USB
Modules" on page 138
"Servicing Front Control
Panel Light Pipe
Assemblies" on page 156
Identifying FRUs in SPARC Enterprise T5120 Servers
Notes
Removing top cover
while the system is
running will cause an
immediate shutdown.
Must be removed to
service hard drive
backplane and front
control panel light pipes.
Light pipe bracket is not
a FRU.
Hard drives must be
removed to service the
hard drive backplane.
Must be removed to
service the hard drive
backplane.
Light pipe bracket is not
a FRU.
FRU Name (If Applicable)
N/A
/SYS/SASBP
N/A
See "Four-Drive Capable
Backplane Configuration
Reference" on page 77 or
"Eight-Drive Capable
Backplane Configuration
Reference" on page 78
/SYS/DVD
/SYS/USBBD
N/A
