Servicing the Hard Drive Cage

These topics explain how to remove and install the hard drive cage.
"Hard Drive Cage Overview" on page 146
■
"Remove the Hard Drive Cage" on page 146
■
"Install the Hard Drive Cage" on page 149
■
Related Information
"Remove the Hard Drive Backplane" on page 152
■
"Remove the Front Control Panel Light Pipe Assemblies" on page 157
■

Hard Drive Cage Overview

The hard drive cage is the mechanical assembly that contains the system hard drives,
DVD/USB module, and hard drive backplane.
You must remove the hard drive cage to access the following components:
Hard drive backplane
■
Front control panel light pipe assemblies
■
Related Information
"Remove the Hard Drive Cage" on page 146
■
"Install the Hard Drive Cage" on page 149
■
"Remove the Hard Drive Backplane" on page 152
■
"Remove the Front Control Panel Light Pipe Assemblies" on page 157
■

▼ Remove the Hard Drive Cage

1. Power off the system.
See"Removing Power From the System" on page 60
