14. Power on the system.
See
Related Information
"Remove the Hard Drive Cage" on page 146
■

Servicing the Hard Drive Backplane

These topics explain how to remove and install hard drive backplanes.
"Hard Drive Backplane Overview" on page 152
■
"Remove the Hard Drive Backplane" on page 152
■
"Install the Hard Drive Backplane" on page 154
■

Hard Drive Backplane Overview

The hard drive backplane is housed in the hard drive cage. It provides data and
control signal connectors for the hard drives. It also provides the interconnect for the
front I/O board, power and locator buttons, and system/component status LEDs.
Note – Each drive has its own Power/Activity, Fault, and Ready-to-Remove LEDs.
Related Information
"Remove the Hard Drive Backplane" on page 152
■
"Install the Hard Drive Backplane" on page 154
■

▼ Remove the Hard Drive Backplane

1. Remove the hard drive cage.
See
2. Remove the No. 1 Phillips screws securing the backplane to the hard drive cage.
■
152 Sun SPARC Enterprise T5120 and T5220 Servers Service Manual • July 2009
"Power On the Server Using the poweron Command" on page
"Remove the Hard Drive Cage" on page
Two screws secure the backplane in the Sun SPARC Enterprise T5120 server. See
the first figure below.
146.
179.
