WAP-VKIT User Manual
Environmental
Operating Temperature: 0° to 50° C (32° to 122° F)
-
Operating Humidity: 90% (non-condensing)
-
Storage Temperature: -10° to +70° C ambient
-
Storage Humidity: 95% (non-condensing)
-
Interfaces
1 Auto sensing 10/100/1000 Base-TX Ethernet (RJ-45)
-
Dual-band radios support any combination of 802.11n, 802.11a, 802.11b, 802.11g
-
6 external antenna interfaces (reverse polarity SMA)
-
Kensington MicroSaver Lock compatible
-
1 RJ45 console port (reserved for future use)
-
5 LEDs for monitoring power, Ethernet activity, 802.11 activity, and 802.11 receive
-
CERTIFICATIONS
Wi-Fi Certified a/b/g/n
-
Safety Standards
UL 60950-1
-
CAN/CSA-C22.2 No. 60950-1
-
IEC 60950-1
-
CTL-W5N- Wireless Virtualization Management Controller
APPLICATION SUPPORT AND OVER-THE-AIR QoS
QoS
Configurable dynamic QoS rules over-the-air resource reservation
-
Automatic, stateful flow detectors for SIP, H.323, Cisco SCCP, SpectraLink SVP, and Vocera
-
User-configurable static and dynamic QoS rules per application (user-defined) and per-user
-
(stations, users, and port numbers)
Call Admissions Control and Call Load Balancing
-
WMM Support
-
SECURITY
SECURITY
Authentication
Combination of captive portal, 802.1x, and open authentication
-
Advanced security using WPA2
-
802.1X with EAP-Transport Layer Security (EAP-TLS), Tunneled TLS (EAP-TTLS), Protected EAP
-
(PEAP)-MSCHAPv2, Smartcard/Certificate, Lightweight EAP (LEAP), EAP-FAST and EAP- MD5,
with mutual authentication and dynamic per-user, per-session unicast and broadcast keys
Secure HTTPS w/customizable Captive Portal utilizing RADIUS
-
Encryption support
Static and dynamic 40-bit and 128-bit WEP keys, TKIP with MIC, AES, SSL, TLS
-
Security Policy
Radius-assisted, per-user and per-ESSID access control via MAC filtering
-
