WAP-VKIT User Manual

5.1

Accessing the Controller Web Interface

To change settings, follow these steps to display the Web Interface:

1. Open a web browser, type the following default IP address for the controller in the

browser's address bar, and press Enter: https://192.168.1.240.

2. If any security or certificate warning windows appear, click "Yes" or "Continue to web page"

to proceed.

3. A pop-up window appears with the Web Management Interface login dialog. Type the

username admin and the default password pakedgec and click OK to continue. The

WLAN Management home page opens, showing the Monitor module and displaying

the Dashboard charts.
