Speaker Connection - CyberData 11085 Installation Quick Reference Manual

System Installation and Connection Options
Generic Ethernet Switch
Line-Out Connection
1 2
Line-out
Connection
Existing Loudspeaker Existing Amplifier
Paging Amplifier

Speaker Connection

802.3af Compliant Ethernet Switch
High Power PoE Switch
1 2
PoE Injector
(High power mode with Injector)
011068 Loudspeaker Paging Amplifier
(up to 25 watts)
Connections
Note: The Sense/Relay and Line-In features are
not supported with the Singlewire firmware.
Line-Out Connection
Speaker Connection
© 2011, CyberData Corporation, ALL RIGHTS RESERVED
Line-Out is 10k Ohm at 2Vpp.
Speaker output is 8 Ohm.
3 4 5 6
IP Phone Informacast Server
(up to 25 watts)
See the VoIP V2 Paging Amplifier Opera-
tions Guide for more information about the
connections.
3 4 5 6
VoIP Phone Informacast Server
1-Sense (+)
2-GND
3-Relay COM
4-Relay NO
5-Line-In(+)
6-Line-In(-)
7-Line-Out(+)
8-Line-Out(-)
9-Spkr Out(+)
10-Spkr Out (-)
930329G
Mounting Template
Quick Reference Quick Reference 930329G © 2011, CyberData Corporation, ALL RIGHTS RESERVED
