CD-4860 2D Image Barcode Scanner
User's Installation and Configuration Manual
Posiflex Technology, Inc.
Limited Warranty
Under all circumstances this manual should be read attentively, before installing and/or using the
product. In no event shall Posiflex Technology, Inc. be liable for any direct, indirect, special,
consequential or incidental damages arising out of the use or inability to use this documentation or
product, even if advised of the possibility of such damages. In particular, Posiflex Technology, Inc. shall
not be liable for any hardware, software, or data that is stored or used with the product, including the
cost of repairing, replacing or recovering the above. Posiflex Technology, Inc. reserves the right to
change parts of the device at any time without preceding or direct announcement to the client.
Posiflex Technology, Inc. reserves the right to revise this manual, and to make changes in the contents
without obligation to notify any person or entity of the revision or change. A serial number appears on
the product. Make sure that this official registration number has not been removed. It should be used
whenever servicing by Posiflex Technology, Inc. or an authorized Posiflex dealer is necessary.
Copyright © 2011, Posiflex Technology, Inc.
This manual is copyrighted, with all rights reserved. Under the copyright laws, this manual may not, in
whole or in part, be copied, photocopied, reproduced, translated or converted to any electronic medium
or machine readable form without prior written consent of Posiflex Technology, Inc.
Due to Posiflex continuing product improvement programs, specifications and features are
subject to change without notice.
January 2011
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CD-4860 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for POSIFLEX CD-4860

  • Page 1 Posiflex Technology, Inc. reserves the right to revise this manual, and to make changes in the contents without obligation to notify any person or entity of the revision or change. A serial number appears on the product.
  • Page 2: Safety & Caution

    Introduction CD-4860 is a cutting-edge gun-type barcode scanner which is designed specifically for retail market. To the brand new series of CD-4860, we add on more user-friendly functions with detachable cable that makes it more easily to be operated by the customers.
  • Page 3 3. Before cleaning the CD-4860, the users must cut off all AC power. Do not use liquid or spray type of detersive to clean the CD-4860. Please use dampish cotton cloth to clean the CD-4860. 4. The outlet must set nearby the CD-4860 for connecting power easily.
  • Page 4: Fcc Warning

    USE OF THE CD-4860 The CD-4860 is very ergonomic and modern designed and very user friendly. It can be connected to your POS or Host system through a RS232 cable, KBW cable, USB cable.
  • Page 5 (b) Communication Cable (RS-232 or Keyboard wedge or USB) (c) Power adaptor (optional) (d) User Manual (e) Transparent Cover Plate. 4. Visually inspect the CD-4860 and accessories for any evidence of physical damage. 5. If anything is missing or appears to be damaged, immediately contact your dealer.
  • Page 6: Usb Interface

    4. Plug the power supply into the AC outlet. Connector USB INTERFACE As like all USB devices, before connecting the CD-4860 with USB interface to your host system, the connect driver must be installed correctly on your host system for CD-4860 operate successful.
  • Page 7 4860 scanner settings with use programming codes or with the Utility Tool. 1.7.1 Changing Scanner Settings with Programming Codes You can set-up your CD-4860 by scan all necessary programming codes for parameters that meet applications. After these scans the CD-4860 is direct permanently saved.
  • Page 8: Return To Default

    Chapter 2 Operating Setting RETURN TO DEFAULT Scan this programming code to set the scanner /Cradle parameters to factory default: Set the scanner to Factory Default Reset all configuration parameters to their factory default setting of the Scanner and Cradle. After this reset you must select all required parameters that meet applications.
  • Page 9: Interface Selection

    INTERFACE SELECTION <Keyboard mode> RS232 Serial Mode <USB HID Mode> USB Com Port Mode SCANNING TRIGGERING <Level> A reading session begins (lighting and decode processing on) when beam is activated and stops when beam is deactivated. Continuous Scanning When the scanner is turned on a continuous reading session begins (lighting and decode processing on).
  • Page 10 Pulse A reading session begins when beam is activated and stays on until a period of inactivity lasting the time specified by the timeout. After the timeout, the scan engine turns off. Flashing Flashing mode allows power up the lighting and decoding are on (no need to activate the trigger line) and after a period of inactivity lasting the time specified by the trigger timeout, the scanner starts flashing, checking for a bar code to be read.
  • Page 11: Trigger Time Out

    Toggle This mode allows lighting and decoding toggle when the trigger line is activated. First trigger activation = lighting and decoding on, Second trigger activation = lighting and decoding off. Presentation This mode allows power up lighting and decoding are on. After a period of inactivity lasting the time specified by the trigger timeout, the lighting turns off or is dimmed.
  • Page 12: Imager Mode

    • Area mode for decode 1D and 2D barcodes. • Linear mode for decode 1D Barcodes. Area mode allows you to set the position of the CD-4860 in any direction regardless of the orientation of the barcode, and perform a good read on 1D and 2D barcodes.
  • Page 13: Good Read Mode

    GOOD READ MODE When active, the scan engine stops the reading session after a successful decoding. - NOTE: this parameter is NOT used with continuous and continuous + flashing modes. <Active> Not Active BUZZER BEEP TONE 2.8.1 Beep Tone Setup <High>...
  • Page 14 2.8.2 Good Read Beeps <One Beep> Two Beeps None 2.8.3 Beep Duration 60 msec <80 msec> 200 msec...
  • Page 15: Good Read Duration

    2.8.4 Timing <During Transmission> Before Transmission After Transmission GOOD READ DURATION 2.9.1 Good Read LED Duration <80 msec> 0.5 sec 1 sec...
  • Page 16 2.9.2 Error Beep <On> 2.9.3 Setup Beep <On>...
  • Page 17 2.10 RS-232 MODE PARAMETERS 2.10.1 Baud rate 1200 2400 4800 9600 <19200> 38400 2.10.2 Data bits Data bits 7 <Data bits 8>...
  • Page 18 2.10.3 Stop bits <Stop bits 1> Stop bits 2 2.10.4 Parity <None> Even 2.10.5 Handshaking RTS/CTS Enable <RTS/CTS disable> ACK/NAK Enable...
  • Page 19 <ACK/NAK Disable> XON/XOFF Enable <XON/XOFF Disable> 2.11 KEYBOARD WEDGE MODE PARAMETER 2.11.1 Terminal Type <IBM PC/AT,PS/2> IBM PC/XT IBM PS/2 25, 30 2.11.2 Capslock Detection Enable <Disable>...
  • Page 20 2.11.3 Upper/Lower Case <No change> Upper Case Lower Case 2.11.4 Send Character by ALT Method Enable <Disable> 2.11.5 Select Numerical Pad <OFF>...
  • Page 21 2.11.6 Time out Between Characters <0 ms> 5 ms 10 ms 25 ms 50ms 100ms...
  • Page 22 2.11.7 Language Selection <US English> UK English Italian Spanish French German Swedish Switzerland Hungarian Japanese...
  • Page 23 Belgium Portuguese Denmark Netherlands Turkey Reserved 1...
  • Page 24: Symbologies Selection

    2.12 SYMBOLOGIES SELECTION Australian Post ON <Australian Post OFF> AZTEC ON <AZTEC OFF> BPO ON <BPO OFF> Canada Post ON <Canada Post OFF> CODABAR ON...
  • Page 25 <CODABAR OFF> Codablock A ON <Codablock A OFF> Codablock F ON <Codablock F OFF> CODE 11 ON <CODE 11 OFF> <CODE 39 ON> CODE 39 OFF CODE 93 ON...
  • Page 26 <CODE 93 OFF> <CODE 128 ON> CODE 128 OFF <GS1-128 ON> GS1-128 OFF <DATAMATRIX ON> DATAMATRIX OFF DataMatrix – Mirrored labels activation On <DataMatrix–Mirrored labels activation off>...
  • Page 27 Dutch Post ON <Dutch Post OFF> <EAN-8 ON> EAN-8 OFF <EAN-13 ON> EAN-13 OFF <EAN 128 ON> EAN 128 OFF GS1 CC-A/B ON...
  • Page 28 <GS1 CC-A/B OFF> GS1 CC-C ON <GS1 CC-C OFF> GS1 DataBar-Omni ON <GS1 DataBar-Omni OFF> GS1 DataBar-Limited ON <GS1 DataBar-Limited OFF> GS1 DataBar-Expand ON <GS1 DataBar-Expand OFF>...
  • Page 29 Infomail ON <Infomail OFF> Interleave 2 of 5 ON <Interleave 2 of 5 OFF> Japan Post ON <Japan Post OFF> Matrix 2 of 5 ON <Matrix 2 of 5 OFF>...
  • Page 30 MaxiCode ON <MaxiCode OFF> MicroPDF417 ON <MicroPDF417 OFF> MSI ON <MSI OFF> <PDF417 ON> PDF417 OFF Planet ON...
  • Page 31 <Planet OFF> PLESSEY ON <PLESSEY OFF> Postnet ON <Postnet OFF> QR Code ON <QR Code OFF> Standard 2 of 5 ON <Standard 2 of 5 OFF>...
  • Page 32 Sweden Post ON <Sweden Post OFF> Telepen ON <Telepen OFF> TLC 39 ON <TLC 39 OFF> <UPC-A ON> UPC-A OFF <UPC-E ON> UPC-E OFF...
  • Page 33: Multi Code

    For a complete overview of support symbologies see appendix. If you need programming codes for symbologies which are not available in this chapter, please contact Posiflex Technical Support department or use CD-4860 utility tool. 2.13 MULTI CODE The multicode function is used configure the scanner to read a series of bar codes and then transmit them all at once.
  • Page 34 Number of bar codes compose: 5 Number of bar codes compose: 6 2.14 POSTAMBLES The scanner can be programmed to output Barcode data according to the following format: [BAR CODE DATA] [POSTAMBLE STRING] Postamble None <CR+LF >...
  • Page 35: A.decimal Value Table

    Appendixes A.DECIMAL VALUE TABLE...
  • Page 36: B.ascii Table

    B.ASCII TABLE...
  • Page 37: C.readable Symbologies

    C.READABLE SYMBOLOGIES 1D Symbologies Symbology Default Enable Note Codabar Code 11 Code 39 Code 93 / 93i Code 128 EAN 8 / EAN 13 EAN 128 / UCC GS1 DataBar (RSS) Omni, Expanded, limited Interleaved 2 of 5 Industrial ISBN ISSN Matrix MSI Code...
  • Page 38 D.TECHNICAL SPECIFICATIONS Physical Characteristics Body Weight Approx. 150 gm Material ABS Plastic Connector RJ 45C 10Pins Dimension 186.8 mm x 81.6 mm x 63.9 mm Operational Light source Visible Red light 650nm + 10nm Scan rate 200scans/sec auto adaptive in linear mode. 56 images/sec auto adaptive in 2D mode.
  • Page 39: E.scan Map

    E.SCAN MAP Typical Reading Distances CD-4860 Typical Reading Distance: These distances are measured in an office environment (250 lux).
  • Page 40 CD-4860 Typical Reading Distances (centimeters) Symbology Density Minimum Maximum Distance Distance Code 39 0.125 mm 7.2 cm 13.1 cm 0.20 3.8 cm 22.5 cm 0.25 3.4 cm UPC / EAN 0.33 Data matrix 0.191 mm 6.3 cm 17.2 cm 0.254 mm 4.8 cm...
