3. Slide the module in so that the clips on either side engage with the server body.
FIGURE 1-11
4. Replace the system configuration card.
Resecure the system configuration card with a cable tie to prevent its accidental
removal.
Power Distribution Board
The power distribution board (PDB) takes power to the server's internal
components.
Caution – The procedures in this section are for the attention of service providers
only.
18
Sun Fire V250 Server Parts Replacement Manual • September 2003
Replacing the System Configuration Card Reader Module
