Hougen, Hougen-Edge, and Punch Pro are proprietary trademarks of Hougen Manufacturing Inc. Ogura and the Ogura logo are propri- etary trademarks of Ogura & co., Ltd. Vac-Pad are propriety trademark of Drillmate PTY, Ltd...
(10569) and then screw the handles into the 3. Complete and mail the Product Registration Card hub. Do not overtighten. NOW. It is important that Hougen Manufacturing, Inc. 8. Your Magnetic Drill was factory adjusted prior to shipping. have a record of product ownership.
Page 4
12. Non-Conforming Cutting Tools Keep Work Area Clean Your Mag Drill is designed to use Hougen Cutters. Cluttered areas and benches invite injuries. The use of drilling tools having different shank styles Keep dirt and chips from under the Cutter area.
The Safety Switch Indicator Light is a New Standard Safety manual. Do not operate tool if switch does not turn Feature on 10914(S) magnetic drills. Its purpose is to inform it on and off. the user that an unsafe condition exists or the safety switch needs adjusting.
2. Remove Access Hole Screw (10977) from back of 7. Open the cutting fl uid valve several full turns (Models housing. 10914 only) 3. Insert 5/32” Allen Wrench into access hole and back off 8. Make certain that cutter is clear of workpiece and turn (counterclockwise) Microswitch Adjusting Screw (10969) motor On by pressing the motor START button.
Page 7
INSTALLING HOUGEN CUTTER IN ARBOR 1. Disconnect power source. 2. Lay drill on its side with feed wheel up to be sure arbor clears table if unit is in normal operating position. 3. Turn feed handles until cutter mounting set screws are exposed and then completely remove the set screws.
Adjusting Arbor Support Bracket for Depth 40451 Bolt 40391 Lock Washer 04375 40299 Spacer 40392 Flat Washer Front Support Bracket 04375 40299 Spacer Front Support Bracket 1" & 2" Depth of Cut 3" Depth of Cut NOTE : Spacers must always be installed with short side toward arbor Drill Maintenance In order to minimize wear on moving parts and insure Coolant bottle must be attached to inducer under...
COOLANT BOTTLE ASSEMBLY - P/N: 40442 See Parts List on Page 15 See Parts List on Page 15 Checking Operation of Checking Operation of Cutting Fluid Arbor Automatic Cutting Reservoir (10914S) Fluid Inducer Note: The automatic cutting fl uid inducer system works 1.
Page 10
MODEL 10914 AND 10914S PANEL COMPONENTS 05193 (10914) Panel Assembly 05217 (10914S) 10914 P/N: 05192 05190 10914S P/N: 05216 02402 04891 04893 90571 05180 White 04879 04878 Wire 04881 04877 Note: When inserting LED into wireing harness make sure red anode lines up...
Page 11
MODEL 10914 & 10914S HOOK UP DIAGRAM Motor Black Black from Circuit Board (P3) White from Circuit Board (P4) Motor White Blue from Power In (White) Circuit Board (P2) Power In (Black) Brown from Circuit Board (P1) Safety Switch (Blue-J4)
Motor Bolt Sequence 1. Tighten bolts in the sequence shown to 5 - 10 in/lb. 2. Retighten bolts in the same sequence to 35 - 40 in/lb. Motor Parts List Part # Description Description Part # Description Description 40258 Motor Cord 40281 Motor Slug 40260...
