DOOR UNIT

Your system may have a door unit equipped with an inter-
com and electric door latch. When a visitor presses the
doorbell, up to four system extensions ring.
When the door bell rings
If your telephone is ringing:
• Press [SPKR] or lift the handset.
• If another extension is ringing:
Dial the PAGE zone code associated with the door unit,
or
Press the flashing [DOOR] button, if defined.
You can now speak with the person at the door.
To open the electric door latch
While connected to the door unit:
• Press [*].
The door latch opens.
36 Executive set with expanded display
