Advanced Setup & Use
The orbitsound M10LX is easy to set up and enjoy, but even better sound may
be achieved by following these guidelines.

Positioning - getting the most from spatial sound

The spatial sound field is produced by the speakers in the sides of the soundbar.
These special signals interact with the main signal (front) to produce true
imaging in your listening environment:
Spatial generation zones
IMPORTANT: The areas marked need to be clear of obstacles in order for the
spatial stereo sound field to work properly.
HINT: Because Orbitsound produces a uniform spatial sound field, the soundbar
does not need to be placed directly in front of the listener. Therefore, placing
the soundbar conveniently so that the sides are not obstructed is more
important than central placement, i.e. on low or high shelf, counter top, below/
above TV

Subwoofer placement

Subwoofer placement does not affect the overall sound much. Position the
subwoofer after optimising placement of the soundbar.
HINT: The sound output from the subwoofer is omni directional, so this can be
placed anywhere.
IMPORTANT: Always make sure that the subwoofer's side with a port (rear) is
clear from obstruction. Covering this port will adversely affect the sound.
