Orbitsound BAR A60 Quick Start Manual

C O N N E C T I N G Y O U R A 6 0
CONNECT POWER
Connect power to the rear of your soundbar
(1) and subwoofer (2). Switch on the
subwoofer power (3).
1
BAR A60
Q U I C K S TA R T G U I D E
CONNECT YOUR TV
Connect your TV using the optical cable included,
Make sure to remove the protective caps on each end
of the cable before plugging the cable in. Connect
the optical cable (4) to your TV and soundbar.
4
TV OPTICAL
AUDIO OUT
5
1
T H A N K Y O U F O R C H O O S I N G O R B I T S O U N D
This guide is all you need to set up your Orbitsound
BAR A60 to start enjoying natural, immersive room
filling airSOUND™.
a i r S O U N D ™ S P E A K E R S
NFC Tag
T O U C H PA N E L B U T T O N S
Input Source
Remote Control Learning
Bluetooth (Hold to pair)
Volume +
Volume -
Power / Standby
NO OPTICAL? (OPTION)
If your TV doesn't have an optical socket,
connect using the 3.5mm AUX cable
supplied to the audio out of your TV and
the AUX input (5) on the airSOUND Bar.
You can table or wall mount your airSOUND Bar
with the included fixings. Please ensure the centre
speakers and side airSOUND speakers are free from
obstacles to get the best sound.
Remote Receiver Display
Remote Learning
Wireless Subwoofer Info
Volume/Bass/Treble
Optical Source
Bluetooth Source
AUX Source
Power/Mute
3
Subwoofer Pairing:
1) Long Press
subwoofer PAIR;
STATUS will flash
2) Long Press
soundbar Vol+ and Vol-
©2014 Orbitsound ltd.
