Setting Up The At91Sam9263-Ek Board; Electrostatic Warning; Requirements; Layout - Atmel AT91SAM9263-EK User Manual

2.1

Electrostatic Warning

The AT91SAM9263-EK evaluation board is shipped in protective anti-static packaging. The board must
not be subjected to high electrostatic potentials. A grounding strap or similar protective device should be
worn when handling the board. Avoid touching the component pins or any other metallic element.
2.2

Requirements

In order to set up the AT91SAM9263-EK evaluation board, the following items are needed:
the AT91SAM9263-EK evaluation board itself.
AC/DC power adapter (12V at 1A), 2.1 mm by 5.5 mm
2.3

Layout

See Figures 2-1 and
AT91SAM9263-EK Evaluation Board User Guide

Setting Up the AT91SAM9263-EK Board

2-2.
Section 2
2-1
6325D–ATARM–26-Aug-09
