1.1
Scope
The AT91SAM9263-EK evaluation kit enables the evaluation of and code development for applications
running on an AT91SAM9263.
This guide focuses on the AT91SAM9263-EK board as an evaluation platform.
1.2
Deliverables
The AT91SAM9263-EK package contains the following items:
an AT91SAM9263-EK board
one A/B-type USB cable
one serial RS232 cable
one RJ45 crossed Ethernet cable
one CD-ROM that allows the user to begin evaluating the AT91 ARM
quickly.
1.3
AT91SAM9263-EK Evaluation Board
The board is equipped with an AT91SAM9263 (324-ball LFBGA package) together with the following:
64 Mbytes of SDRAM memory
4 Mbytes of PSRAM memory on EBI1
256 Mbytes of NANDFlash memory
One NOR Flash memory (footprint only)
One 1.8" Hard disk connectors
One TWI serial memory
One USB device port interface
Two USB Host port interfaces
One RS232 serial communication port
One DBGU serial communication port
One serial CAN 2.0B communication port
One JTAG/ICE debug interface
One Ethernet 100-base TX with three status LEDs
One AC97 Audio DAC
AT91SAM9263-EK Evaluation Board User Guide
Section 1
Overview
®
®
Thumb
32-bit microcontroller
6325D–ATARM–26-Aug-09
1-1
