Icemaker Controls

Spill Shelf
Display after power failure:
After a power failure, the
display will reset based
on freezer temperature.
If the freezer temperature
is below 40°F, the display
will retain the settings
prior to power loss. The
chart at the right describes
the possible settings.
To Use the Dispenser
Select CUBED , CRUSHED
or WATER .
Press the glass gently against the middle
of the dispenser pad.
The spill shelf is not self-draining.
To reduce water spotting, the shelf and
its grille should be cleaned regularly.
If no water is dispensed when the
refrigerator is first installed, there may be
air in the water line system. Press the
dispenser arm for at least two minutes to
remove trapped air from the water line
and to fill the water system. To flush out
impurities in the water line, throw away
the first six glassfuls of water.
CAUTION:
Never put fingers
or any other objects into the ice crusher
discharge opening.
Locking the Dispenser
Press the LOCK/LIGHT
HOLD FOR
3 SECS
button for 3 seconds
TO ACTIVATE
to lock the dispenser
LOCK
and control panel. To
unlock, press and hold
the button again for
3 seconds.
LIGHT
Dispenser Light
This button turns
HOLD FOR
3 SECS the night light on the
TO ACTIVATE
dispenser on and off.
LOCK
The light also comes
on when the dispenser
pad is pressed. If this
light burns out, it should
LIGHT
be replaced with a 6 watt
12V maximum bulb.
Control Function
Refrigerator Set
Temperature
Freezer Set Temperature
Door Alarm
Dispenser Option
Quick Ice
Reset Filter
Lock
Dispenser Light
– 11 –
Quick Ice
QUICK ICE
Door Alarm
DOOR ALARM
Note: When Q
the freezer temperature operates
at -9°F for 48 hours or until
is pressed again. There is no
ICE
change of temperature on the
display panel.
In the event of a power loss, if the
freezer temperature is above 40°F,
Quick Ice will not restart. Below
40°F, the refrigerator will return to
the Quick Ice mode
Freezer<40°F
Previous Setting
Previous Setting
Previous Setting
Previous Setting Default (Crushed Ice)
Previous Setting
Previous Setting
Previous Setting
Previous Setting
When you need ice
in a hurry, press this
button to speed up ice
production. This will
increase ice production
for the following
48 hours or until you
press the button again.
To turn the Door Alarm
on, press the DOOR
ALARM button once.
The ACTIVE light will
come on. To turn it off,
press it again. When the
DOOR ALARM is active,
the ACTIVE light will
flash if you open the
door and beep if you
keep the door open for
more than 2 minutes.
The light goes out and
the beeping stops when
you close the door.
I is selected,
UICK CE
QUICK
.
Freezer>40°F
Default 37°F
Default (0°F)
Previous Setting
OFF
Previous Setting
Previous Setting
OFF
