Rider's Seat

cgig
1. Rider's seat
To remove the rider's seat, remove the rear
seat (see page 46).
Grasp the rider's seat on either side, and slide
it rearwards and upwards for complete
removal from the motorcycle.
To refit the seat, engage the seat's front rail
into the bracket at the rear of the fuel tank
and lower the rear rail in to the rear brackets.
Push down firmly on the rear of the seat.
Refit the rear seat (see page 46).
General Information

Rider's Seat Height Adjustment

1
3
cgih
1. Rider's seat
2. Front seat height adjuster
3. Rear seat height adjuster
4. Low seat height position (rear shown)
5. High seat height position (rear
shown)
The rider's seat is adjustable for height by
approximately 25 mm.
To adjust the rider's seat:
Remove the rider's seat (see page 47).
Reposition both seat height adjusters to the
higher or lower position as required. Ensure
both adjuster rails are fully engaged in their
brackets on the seat.
Refit the rider's seat (see page 47).
1
2
5
4
