Open Date EUROCODE 150 Operator Instructions Manual page 36

EUROCODE AIRBOURNE NOISE EMISSIONS
Comprehensive tests have been carried out with the Sprint fitted in a standard printer frame
and mounted onto a typical label applicator. Measurements were taken at 1.6 metres above
floor level and approximately 1 metre away from the printer in all directions.
The measuring equipment used for conducting the tests was a Digital Sound Level Meter, type
d-1405E supplied by Lucas CEL. Before the tests were carried out the instrument was
calibrated and fitted with a foam windshield.
The results shown below are based upon a standard type installation for the printer, the
operating air pressure was set at 6 bar and the air flow restrictors correctly adjusted.
The noise levels shown below are the equivalent continuous "A-weighted" sound pressure
levels in decibels "dB(A)".
PRINTS PER MINUTE
Eurocode-Digi50 06/08/13
100
200
300
400
NOISE LEVEL - DECIBELS
(dB)
65
68
70
74
