Open Date EUROCODE 150 Operator Instructions Manual page 28

When ordering spare parts please use the Stock Reference.
Item numbers refer to those on the following assembly drawings.
ITEM DESCRIPTION
1 Magazine plate
2a Take-off hub assy
2b Rewind hub assy
3 Hub spindle
4 Door assy
5 Roller spindle
6 Anchor
7 Foil guide
8 Bush
9 Drive roller spindle
10 Dancing bar
11 Roller
12 Bush
13 Drive roller assy
14 Dancing arm
15 Pulley
16 Spring post
17 Spring post
18 Yoke
19 Spindle
20 Pinch roller assy
21 Pinch roller spindle
22 Washer
23 Spacer
24 Support
25 Drive belt
26 Bearing
27 Brake strap
28 Bearing
29 Handle
30 Grub screw
31 Circlip
32 Seal
33 Clutch bearing
34 Spring
35 Spring
36 Grub screw
37 CSK screw
38 Button screw
39 Spring
40 Dowel pin
41 Button screw
42 Pan head screw
43 CSK screw
44 Pan head screw
45 CSK screw
46 Grub screw
47 Button screw
48 Washer
49 Cylinder liner
50 Spring clip
51 Washer
52 Hinge block
53 Handle
54 Back disc
55 Drive boss
56 Back disc
57 Brake hub
58 Roller
59 Grub screw
60 Main body
61 Piston
62 Bottom cap
63 Databox packing
64 Guide pin
Eurocode-Digi50 06/08/13
EUROCODE PARTS LISTS (1 of 3)
STOCK REF.
N/A
HUB620201
HUB620202
SPI620003
DOO620203
SPI620005
ANC190006
GUI620006
BUS190008
SPI620007
DAN620008
ROL620009
BUS190012
DRI620204
ARM620011
PUL190015
SPR190016
SPR190017
YOK620012
SPI620013
PIN620205
SPI620015
WAS620016
SPA120042
SUP190024
DRI110022
BEA520003
BRA620038
BEA521006
HAN530502
CLI530024
SEA512034
BEA521504
SPR530034
SPR530035
SPR530008
LIN620017
SPR530001
WAS120035
HIN122006
HAN120079
DIS121009
DRI120052
DIS121008
BRA120063
ROL620018
N/A
PIS620020
N/A
PAC190028
PIN620022
QTY NOTES
1
1 Includes items 26,44,50,56,57.
1 Includes items 26,42,44,50,54,55
See supplementary list for Eurocode 300.
2 See supplementary list for Eurocode 300.
1 Includes items 52,74,112.
6
1
1 See supplementary list for Eurocode 300.
2
1
1
1
1
1 Includes items 15,22,32,33,45.
1
1
2
1
1
1
1 Includes item 28.
1
1
1
2
1 Part of Spring Set.
See supplementary list for EC 300 & 180.
6 See supplementary list for Eurocode 300.
1 See supplementary list for Eurocode 300.
2
1
1 M5x6
2
1 Part of Seal Kit.
2
1 Part of Spring Set
1 Part of Spring Set.
2 M4x4
1 M4x20
7 M4x8
1 Part of Spring Set.
1 6 dia x 28
4 M5x20
2 No.2-56 x 1/4"
2 M4x25
4 No.2-56 x 1/8"
1 M4x8
1 M3x6
1 M3x6
1 M3
1
2 Part of Spring Set.
8
1
2
1
1 See supplementary list for Eurocode 300.
1
1
6
1 M4x5
1
1 Piston/Seal assy ref. PIS620200
1
1
1
Page 28
