CAUTION - Read Manual
DO NOT attempt to operate the pump until the Safety, General
Information and Inspection sections of this manual have been
read and thoroughly understood .
This section is intended to assist the operator with the initial
start-up of the trash pump. It is extremely important that this
section be read carefully before attempting to use the pump in
the field.
Starting the Engine ( HONDA engine)
1. Place the engine fuel valve lever (Figure 6) to the "ON"
position.
Figure 6. Engine Fuel Valve Lever (ON Position)
2. Move the throttle lever (Figure 7) away from the slow
position, about 1/3 of the way toward the fast position.
Figure 7. Throttle Lever (1/3 Start Position)
QP303H CENTRIFUGAL PUMP — PARTS MANUAL— REV. #1 (09/09/10) — PAGE 17
QP303H — INITIAL START-UP (ENGINE)
3. Place the choke lever (Figure 8) in the " OPEN " position if
starting a cold engine.
Figure 8. Engine Choke Lever (Open)
4. Place the choke lever (Figure 9) in the " CLOSED " position
if starting a warm engine or the temperature is warm.
Figure 9. Engine Choke Lever (Closed)
5. Place the engine ON/OFF switch (Figure 10) in the " ON "
position.
Figure 10. Engine ON/OFF Switch (ON Position)
