Multi-gas Monitor
Reference Guide
A companion resource for the
Ventis MX4 Product Manual
Part Number: 17152355-1
Version 2
www.indsci.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ventis MX4 and is the answer not in the manual?

Questions and answers

Related Manuals for Industrial Scientific Ventis MX4

Summary of Contents for Industrial Scientific Ventis MX4

  • Page 1 Multi-gas Monitor Reference Guide A companion resource for the Ventis MX4 Product Manual Part Number: 17152355-1 Version 2 www.indsci.com...
  • Page 2 Ventis™ MX4 Reference Guide © 2010 Industrial Scientific Corporation...
  • Page 3 WARNING: this is NOT a Product Manual. Prior to unpacking and using the monitor, all Ventis MX4 users should download, read, and understand the Product Manual available online at the Ventis MX4 Resource Center at www.indsci.com/VentisMX4resources.
  • Page 4 Ventis™ MX4 Reference Guide Ventis MX4 Resources The Ventis MX4 Product Manual is the primary resource, within a full suite of learning tools, developed for the monitor user. Its step-by-step “walk through” format covers everything from unpacking to set-up, operation, and service.
  • Page 5 Failure to perform certain procedures or note certain conditions may impair the performance of this product. For maximum safety and optimal performance, please download, read, and understand the Product Manual available online at the Ventis MX4 Resource Center at www.indsci.com/VentisMX4resources. Personnel CAUTION: For safety reasons, this equipment must be operated and serviced by qualified personnel only.
  • Page 6 POSITIVE “+” AND NEGATIVE “-“ ORIENTATION. FAILURE TO FOLLOW PROPER BATTERY ORIENTATION WILL RESULT IN DAMAGE TO THE INSTRUMENT. WARNING: The Ventis MX4 is only approved for use with AAA battery types Energizer EN92 and Duracell MN2400. Do NOT mix battery types. Recommended Practices...

  • Page 7: Process Overview

    Where a button symbol appears, a press on that button will result in the next process step as indicated by the arrow symbol. When an arrow appears without a button symbol, no button presses are required to get to the next step. ON/OFF/MODE ENTER © 2010 Industrial Scientific Corporation...
  • Page 8 Figure 2, Configuration. Gas Monitoring Screen Days Since Last Calibration Screen Zero Initiate Screen (if enabled) Press ON/OFF/MODE to bypass zero. Press ENTER to begin the zero ► process. Refer to Figure 3, Quick Calibration © 2010 Industrial Scientific Corporation...
  • Page 9 Testing. Peak Readings Screen Press ENTER to clear the peak values, if desired. TWA Readings Screen Press ENTER to clear the readings, if desired. STEL Readings Screen Press ENTER to clear the readings, if desired. © 2010 Industrial Scientific Corporation...
  • Page 10 Press ON/OFF/MODE to bypass zero and begin the zero and calibration process. calibration process. ► Refer to Figure 3, Quick Calibration. Calibration Mode Selection Screen Press ENTER to edit value, if needed. 0 = standard calibration 1 = quick calibration © 2010 Industrial Scientific Corporation...
  • Page 11 For each flashing value: press ENTER to edit value, if needed; press ON/OFF/MODE to set. Calibration Gas Set Screen Press ENTER to begin. For each flashing value: press ENTER to edit value, if needed; press ON/OFF/MODE to set. © 2010 Industrial Scientific Corporation...
  • Page 12 Bump Due Warning (0=disable/off ; 1=enable/on) Bump Test Time (.5-7.0 days) Bump Test Percentage (50-99%) Bump Test Response time (30-300 seconds) Alarm Latch Set Screen Press ENTER to edit, if needed. 0 = Normal 1 = Latching © 2010 Industrial Scientific Corporation...
  • Page 13 Press ENTER to edit, if needed. Value range: 1-365 days Security Code Set Screen Press ENTER to edit, if needed. Value range: 000-999 Language Selection Screen Press ENTER to edit, if needed. E = English F=French d = German © 2010 Industrial Scientific Corporation...
  • Page 14 Calibration Apply Gas Screen* Displays expected gas concentrations for toxic and LEL sensors installed; waits five minutes for gas. Press ON/OFF/MODE** to terminate calibration and return to the Gas Monitoring Screen. ►Refer to Figure 1, Operation/Start-up. © 2010 Industrial Scientific Corporation...
  • Page 15 *For a standard calibration, this series of display screens cycle for each toxic and LEL sensor as it calibrates: apply gas, in-progress, and results screens. **For a standard calibration, press ON/OFF/MODE as each sensor flashes. © 2010 Industrial Scientific Corporation...
  • Page 16 Bump Test Results (Pass) Screen* Alternately displays final sensor reading and pass status screens. ►Refer to Figure 1, Operation/Start-up. Bump Test Results (Fail) Screen* Alternately displays final sensor reading and fail status screens. © 2010 Industrial Scientific Corporation...
  • Page 17 ►Refer to Figure 3, Quick Calibration. *For a standard bump test, this series of display screens cycle for each sensor as it calibrates: apply gas, in-progress, and results screens. **For a standard bump test, press ON/OFF/MODE as each sensor flashes. © 2010 Industrial Scientific Corporation...
