MX4 External Battery Charger Adaptor User Guide
Part Number: 17153953-1
Warnings and Cautionary Statements
Failure to perform certain procedures or note certain conditions may
impair the performance of this product. For maximum safety and
optimal performance, please read and follow the procedures and
conditions listed below.
Read all instructions before using the product.
Do not touch battery contacts.
Use in an area known to be nonhazardous.
Capabilities and Compatibilities
The MX4 External Battery Charger Adaptor can charge the MX4 Li-ion battery
pack* or Li-ion extended range battery pack*.
The charger adaptor is compatible with the following MX4 charger products*;
Single-unit Charger
Single-unit Charger/Datalink
Single-unit Automotive Charger, 12VDC, with Plug
Single-unit Truck-mount Charger, 12VDC, with Plug
Single-unit Truck-Mount Charger, 12VDC, Hard Wired
6-Unit Charger
*Not included with the charger adaptor.
Supplies Checklist
MX4 Li-ion battery pack (not included) or MX4 Li-ion extended range battery pack
(not included)
Charger (not included; Single-unit Charger shown)
Charger adaptor
Hardware Overview
Charging contacts
Extended range battery
cradle
Cradle latch
Battery holder
Instructions for Use
See next page.
Li-ion battery pack
charging surface
Charging contacts
