THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
1 74207-G01
2 72028-G01
3 72117-G01
4 72037-G01
5 72618-G01
6 00560-G1
7 11098-G5
8 74207-G03
9 70291-G01
10 14158-G1
11 12262-G1
12
13 00665-G9
14 70290-G02
15 70291-G01
16 70289-G02
17 11098-G5
18 70469-G01
19 76418-G01
20 10435-G1
21 10194-G1
22 00532-G6
1 2 3 4 5
HEAVY DUTY LEAF SPRING.............................................................................
ISOMOUNT BASE PLATE ..................................................................................
ISOMOUNT BUSHING........................................................................................
ISOMOUNT CAP.................................................................................................
'U' BOLT, 3/8 - 16 X 2" X 2 1/2" LG ....................................................................
WASHER, 3/8" ....................................................................................................
LOCK NUT, 3/8 - 16 ............................................................................................
HEAVY DUTY LEAF SPRING (TG5 ONLY) .......................................................
FLANGED BUSHING ..........................................................................................
SHOULDER BOLT, 3/8 - 16 x 3 1/4" LG .............................................................
LOCK NUT, 3/8 - 16 ............................................................................................
BOLT, 3/8 - 16 X 3 1/2" LG (STAINLESS STEEL)..............................................
SHACKLE PLATE ...............................................................................................
FLANGED BUSHING ..........................................................................................
SPACER..............................................................................................................
LOCK NUT, 3/8 - 16 ............................................................................................
SHOCK ABSORBER(TG5 ONLY) ......................................................................
SHOCK ABSORBER...........................................................................................
SHOCK ABSORBER WASHER ..........................................................................
RUBBER BUSHING ............................................................................................
NUT, 3/8 - 24.......................................................................................................
Service Parts Manual
REAR SUSPENSION
DESCRIPTION QTY.
1
2
2
2
4
8
8
1
4
2
2
4
4
8
4
4
2
2
8
8
4
Page Q-2
