E-Z-GO Cushman Service & Parts Manual page 88

FRONT SUSPENSION/STEERING
Where applicable, THE USE OF NON UL PARTS WILL VOID ANY UL LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
58 *
59 70694-G01
60 *
61 70961-G01
62 12416-G2
63 11391-G8
64 70638-G01
65 70695-G01
66 50641-G1
67 50209-G2
68 10387-G2
69 10389-G3
70 00464-G6
71 01068-G01
72 70667-G02
73 70667-G03
74 00532-G7
75 00560-G2
76 00734-G1
77
78
79 70607-G01
80
81 70758-G03
82 70610-G01
83 28569-G01
84 01022-G01
85
86 70758-G04
87 70610-G02
Page M-5
1 2 3 4 5
STEERING BOX INSTALLATION TAG.........................................................
RACK EXTENSION ......................................................................................
JAM NUT, 1/2 - 20.........................................................................................
RACK BOOT.................................................................................................
WIRE TIE ......................................................................................................
CLAMP, 1 13/16 - 2 3/8"................................................................................
PINION SEAL ...............................................................................................
RACK BALL JOINT (INCLUDES ITEMS 66 - 69) .........................................
RUBBER BOOT .....................................................................................
CASTELLATED NUT, 7/16 - 20 ..............................................................
COTTER PIN, 3/32" X 1" LG ...............................................................................
GREASE FITTING, STRAIGHT..............................................................
BOLT, 7/16 - 14 X 2 3/4" LG ................................................................................
BOLT, 7/16 - 14 X 3 1/2" LG ................................................................................
SPACER ..............................................................................................................
SPACER (SHORT) ..............................................................................................
NUT, 7/16 - 14 .....................................................................................................
FLAT WASHER, 7/16" .........................................................................................
LOCK NUT, 7/16 - 14 ..........................................................................................
STEERING SHAFT .............................................................................................
STEERING COLUMN KIT (INCLUDES ITEMS 82 - 84) .....................................
STEERING COLUMN ...................................................................................
STEERING COLUMN BUSHING..................................................................
SCREW, #6 - 20 X 5/16" LG .........................................................................
STEERING COLUMN KIT (HORN) (INCLUDES ITEMS 87 - 89) .......................
STEERING COLUMN ...................................................................................
Service Parts Manual
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
2
1
2
1
1
7
3
1
1
1
1
1
1
1
