E-Z-GO Cushman Service & Parts Manual page 103

THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
1 71751-G**
2
3 71888-G**
4 71701-G01
5 71702-G01
6 01110-G01
7 00664-G7
8 00415-G2
9
10 71875-G**
11 71877-G01
12 71877-G02
13 01110-G01
14 00415-G2
15
16
17 71632-G01
18 71204-G02
19 71868-G01
20 32805-G6
21 70836-G0**
22 27731-G01
23 15717-G5
24 23726-G4
25 00427-G8
26 00439-G8
27 00675-G1
28 71883-G01
29 23726-G9
30 11098-G6
1 2 3 4 5
SEAT BACK ASSEMBLY ....................................................................................
SEAT BOTTOM (INCLUDES ITEMS 4 - 8) (SHUTTLE 4 & 6) ............................
HIP RESTRAINT (PASSENGER SIDE)........................................................
HIP RESTRAINT (DRIVER SIDE) ................................................................
WASHER, 1/4" (STAINLESS STEEL)...........................................................
LOCKWASHER, 1/4" (STAINLESS STEEL) .................................................
BOLT, 1/4 - 20 X 1 1/4" LG............................................................................
SEAT BOTTOM (INCLUDES ITEMS 11 - 14) (TG5) ...........................................
HIP RESTRAINT (PASSENGER SIDE)........................................................
HIP RESTRAINT (DRIVER SIDE) ................................................................
WASHER, 1/4" (STAINLESS STEEL)...........................................................
BOLT, 1/4 - 20 X 1 1/4" LG............................................................................
REAR HAND HOLD BAR ....................................................................................
BOLT, 1/4 - 20 X 2" LG ........................................................................................
SEAT BACK BRACKET ......................................................................................
TRIM, BLACK......................................................................................................
SEAT POD ..........................................................................................................
ASHTRAY............................................................................................................
ACORN NUT, 3/8 - 16 .........................................................................................
SPACER, 5/16"....................................................................................................
BOLT, 3/8 - 16 X 2" LG ........................................................................................
BOLT, 5/16 - 18 X 2" LG ......................................................................................
WASHER, 3/8" (STAINLESS STEEL) .................................................................
RUBBER WASHER, 5/8" ....................................................................................
SPACER, 3/4"......................................................................................................
LOCK NUT, 5/16 - 18 (STAINLESS STEEL) .......................................................
Service Parts Manual
DESCRIPTION
SEATING
QTY.
1
1
1
1
8
8
8
1
1
1
8
8
1
4
2
1
1
1
2
2
2
3
5
3
3
3
Page R-4
