E-Z-GO Cushman Service & Parts Manual page 36

BODY
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
241 71609-G01
242 600034GXX
243 10570-G10
244 10570-G10
245 10570-G10
246 10570-G12
247 23726-G2
248 600038-G01
249 00438-G8
250 00559-G8
251 11098-G6
252 00715-G2
253 70200-G01
254 75900-G02
255 00427-G2
256 00560-G1
257 11098-G4
258 70440-G04
259
260
261 600264-G01
262 28272-G01
263 11027-G2
264
265 00715-G2
266 11098-G6
Page C-17
1 2 3 4 5
SEAT HINGE .......................................................................................................
SEAT WRAP PANEL ...........................................................................................
RIVET, 5/32" X 9/16" LG (STAINLESS STEEL) ..................................................
RIVET, 5/32" X 9/16" LG (STAINLESS STEEL) ..................................................
RIVET, 5/32" X 9/16" LG (STAINLESS STEEL) ..................................................
RIVET, 1/4" X 9/16" LG .......................................................................................
WASHER, 1/4" ....................................................................................................
SEAT FRAME WELDMENT ................................................................................
BOLT, 5/16 - 18 x 1"LG........................................................................................
WASHER, 5/16....................................................................................................
LOCK NUT, 5/16 - 18 ..........................................................................................
BOLT, 5/16 - 18 X 13/16" LG ...............................................................................
BOLT, 3/8 - 16 X 3/4" LG .....................................................................................
SEAT BACK BRACKET.......................................................................................
BOLT, 3/8 - 16 X 1" LG ........................................................................................
WASHER, 3/8" ....................................................................................................
LOCK NUT, 3/8 - 16 ............................................................................................
SEAT FRAME......................................................................................................
F&R BRACKET ...................................................................................................
SCREW, 1/4 - 20 X 1...........................................................................................
LOCK NUT, 1/4 - 20 ............................................................................................
BOLT, 5/16 - 18 X 13/16" LG ...............................................................................
LOCK NUT, 5/16 - 18 ..........................................................................................
Service Parts Manual
DESCRIPTION QTY.
2
1
5
2
4
2
4
1
2
2
2
4
2
2
4
4
4
1
1
2
2
2
2
