E-Z-GO Cushman Service & Parts Manual page 114

WEATHER PROTECTION
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
31 75274-G02
32 19853-G1
33 00665-G5
34 00679-G1
35 00771-G5
36 00891-G5
37 00440-G4
38 00441-G2
39 00879-G1
40 75048-G01
41 00905-G8
42 00440-G2
43 75240-G01
44 00163-G2
45 00642-G8
46 11098-G6
47 18716-G2
48 00567-G8
49 01010-G01
50
51 75485-G01
52 75487-G02
53 75487-G01
54 00665-G5
55 00679-G1
56 00771-G5
57 00891-G5
58 19853-G1
59 75488-G01
60 00440-G2
Page T-5
1 2 3 4 5
REAR STRUT (PASSENGER SIDE)............................................................
END CAP, 1".................................................................................................
BOLT, 3/8 - 16 X 1 3/4" LG (STAINLESS STEEL) .......................................
WASHER, 3/8" (STAINLESS STEEL) ..........................................................
NYLON WASHER, 3/8" ................................................................................
LOCK NUT, 3/8 - 16......................................................................................
BOLT, 5/16 - 18 X 2 1/2" LG .........................................................................
BOLT, 5/16 - 18 X 3 1/4" LG .........................................................................
WASHER, 3/8" ..............................................................................................
SPACER, 1/2" ...............................................................................................
LOCK WASHER, 5/16" .................................................................................
BOLT, 5/16 - 18 X 2 1/4" LG .........................................................................
HANDLE .......................................................................................................
SCREW, 1/4 - 20 X 1 1/4" LG .......................................................................
WASHER, 5/16" ............................................................................................
LOCK NUT, 5/16 - 18 (STAINLESS STEEL) ................................................
SPACER, 1" ..................................................................................................
LOCK WASHER, 5/16" .................................................................................
TEE NUT, 1/4 - 20 ........................................................................................
SUN TOP KIT (TE5/TG5) (INCLUDES ITEMS 52 - 69) ......................................
REAR SUPPORT (DRIVER SIDE) ...............................................................
REAR SUPPORT (PASSENGER SIDE) ......................................................
BOLT, 3/8 - 16 X 1 3/4" LG (STAINLESS STEEL) .......................................
WASHER, 3/8" (STAINLESS STEEL) ..........................................................
NYLON WASHER, 3/8" ................................................................................
LOCK NUT, 3/8 - 16......................................................................................
END CAP, 1".................................................................................................
FRONT SUPPORT .......................................................................................
BOLT, 5/16 - 18 X 2 1/4" LG .........................................................................
Service Parts Manual
DESCRIPTION QTY.
1
2
4
8
4
4
4
2
4
2
4
4
5
10
12
6
2
10
10
1
2
2
4
8
4
4
2
2
4
