E-Z-GO Cushman Service & Parts Manual page 93

THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
1 605523
2 72282-G01
3 72229-G01
4 72230-G01
5 20048-G2
6 *
7 72232-G01
8
9 605521
10
11 00438-G8
12 00559-G8
13 70483-G01
14 11098-G6
15
16
17
18 72084-G01
19 17470-G1
20 18292-G1
21 72873-G01
22 00114-G6
23
24 17470-G1
25 11391-G4
26 27184-G01
27
28 17618-G1
29 22280-G1
1 2 3 4 5
FUEL TANK (FOR ELECTRIC FUEL GAUGE) ...................................................
FUEL TANK CAP.................................................................................................
FUEL LEVEL SENDER ADAPTER .....................................................................
SCREW, #6 - 32 X 1/2" LG..................................................................................
FUEL LEVEL SENDER (ELEC. FUEL GAUGE) (INCLUDES ITEMS 6, 7) ........
GASKET .......................................................................................................
SCREW, #10 - 32 x 3/4" LG..........................................................................
FUEL TANK (FOR VEHICLES WITHOUT GAUGE) ...........................................
BOLT, 5/16 - 18 X 1" LG ......................................................................................
WASHER, 5/16" ..................................................................................................
SPACER ..............................................................................................................
LOCK NUT, 5/16 - 18 .........................................................................................
FUEL FILTER ......................................................................................................
TUBING, 1/4" ID X 1/2" OD (BULK), 3 1/4" LG ................................................... A/R
CLAMP ................................................................................................................
FUEL PUMP........................................................................................................
SCREW, 1/4 - 14 X 3/4" LG.................................................................................
TUBING, 16" LG (BULK) .................................................................................... A/R
HOSE CLAMP, 1/4" .............................................................................................
PULSE TUBING, 16" LG (BULK)......................................................................... A/R
WIRE TIE ............................................................................................................
VINYL TRIM, 6 1/4" LG (BULK) .......................................................................... A/R
Service Parts Manual
DESCRIPTION
FUEL SYSTEM
QTY.
1
1
1
2
1
1
5
1
1
4
1
3
1
5
1
2
3
3
Page N-2
