E-Z-GO Cushman Service & Parts Manual page 13

When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
31 17838-G1
32 17255-G1
33 10387-G3
34 74432-G01
35 12064-G6
36 14390-G10
37 12730-G1
38
39 72201-G02
40 72201-G03
41 17313-G1
42 17618-G1
43 72402-G01
44 00559-G8
45 25799-G02
46 27844-G01
47 15766-G1
48 27512-G01
49 *
50 00715-G2
51 70135-G01
52
53 72401-G01
54 00568-G4
55 00545-G4
56
57 72155-G01
58 72154-G01
59
60 00544-G4
1 2 3 4 5
NYLON BUSHING ........................................................................................
TEFLON WASHER, 5/16".............................................................................
COTTER PIN, 3/32" X 3/4" LG .....................................................................
PEDAL PIVOT PIN .......................................................................................
PUSH NUT, 9/32"..........................................................................................
LOCK NUT, #10 - 24 .....................................................................................
WHEEL BEARING GREASE (NOT ILLUSTRATED) .................................... A/R
WIRE HARNESS (PEDAL BOX) ..................................................................
WIRE HARNESS (PEDAL BOX) (TG5) ........................................................
FLEX LOOM (BULK)..................................................................................... AR
WIRE TIE ......................................................................................................
ACCELERATOR CABLE ..............................................................................
WASHER, 5/16" ............................................................................................
ACCELERATOR PEDAL ASSEMBLY (INCLUDES ITEMS 47 - 49).............
ACCELERATOR PEDAL PAD KIT (INCLUDES ITEMS 47 - 48)............
OVAL RIVET, 3/16" X 7/16" LG........................................................
ACCELERATOR PEDAL PAD .........................................................
ACCELERATOR PEDAL
BOLT, 5/16 -18 X 4/5" LG ....................................................................................
PEDAL PIVOT COVER .......................................................................................
CHOKE CABLE (WITH NUTS) ...........................................................................
LOCK WASHER, 9/16"........................................................................................
JAM NUT, 9/16 - 18 .............................................................................................
RETAINER ..........................................................................................................
CHOKE CABLE ADAPTER .................................................................................
JAM NUT, 5/16 - 24 .............................................................................................
Service Parts Manual
DESCRIPTION
ACCELERATOR
QTY.
Page A-4
3
1
1
1
1
1
1
1
2
1
1
1
1
6
1
4
1
1
1
1
1
1
2
