E-Z-GO Cushman Service & Parts Manual page 90

FRONT SUSPENSION/STEERING
Where applicable, THE USE OF NON UL PARTS WILL VOID ANY UL LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
118
119 70876-G02
120 70897-G02
121 70902-G01
122 01069-G01
123 70902-G02
124 01069-G02
125 00734-G1
126 10044-G01
Page M-7
1 2 3 4 5
TIE ROD ASSEMBLY (INCLUDES ITEMS 120 - 124) ........................................
THREADED ROD (24" LG)...........................................................................
TIE ROD END (LEFT HAND THREADS) .....................................................
JAM NUT, M12 X 1.25 - 05 (LEFT HAND THREADS)..................................
TIE ROD END (RIGHT HAND THREADS)...................................................
JAM NUT, M12 X 1.25 - 05 (RIGHT HAND THREADS) ...............................
LOCK NUT, 7/16 - 14 ..........................................................................................
CAP, VINYL .........................................................................................................
Service Parts Manual
DESCRIPTION QTY.
1
1
1
1
1
1
2
2
